Denon AVR-2313 User Manual

208
Ref. No. Part No. Part Name Remarks Q'ty New
C4067 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
z
C4140,4141 963134011730S C,CERAMIC DE1B3KX471KB4BL01 D00847127H010S
z
C4142 963132011940S C,CERAMIC DE2F3KY103MB3BM02 D008103589010S
z
C4143 nsp C,FILM 0.1UF-K/275V D02110407H010S
C4145-4147 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
z
C4148,4149 963132011940S C,CERAMIC DE2F3KY103MB3BM02 E2,E1C D008103589010S
C4151 943134501590S C,ELECT GE 105C 100UF-M/200V D04110108G000S
C4151 963134010200S C,ELECT 100UF-M/400V E2,E1C D04110108K000S
C4152 963134010210S C,ELECT 47UF-M/25V D041470084050S
C4153 963132010120S C,CERAMIC DEHR33A102KB2B D00810207Q010S
C4154 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4155 963134010190S C,ELECT 10UF-M/50V D041100087050S
z
C4156 963132011930S C,CERAMIC DE1E3KX222MB4BL01 D00822248H010S
C4159,4160 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4161 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C4162-4164 963134010220S C,ELECT5600UF-M/6.3V D041562081001S
C4166 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
OTHERS PARTS GROUP
BKT4000-4002 nsp BRACKET t1.0+Sn plating /PCB MTG 4010214876000S
BKT4141 nsp BRACKET 0.8t/SCREW 4010210196100S
BKT4142 nsp BRACKET SCREW 4010210196000S
CLAMP400 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN402 nsp CN,WIRE 230MM/5P 5264-05 L000231050050S
CN403 nsp CN,WIRE 2MM 170MM/10P 20010HS-10 L002171100050S
CN405 nsp CN,WIRE,I9CN,WIRE L000161030050S
CN4141 nsp CN,WIRE 370MM/5P L000371050010S
CP4001 nsp CN.WAFER 7.92MM 35328-0360 L108353280360S
CP4002 nsp CN.WAFER 13P STRAIGHT L101200101310S
CP4142 nsp CN.WAFER 7.92MM LWBP1143-02P L108011430210S
DZ4000 963202500330D D,ZENER ZJ6.8B-0.5W K06006R844522S
z
F4140 963652010510S FUSE T2A/250V E3 N751502001160S
z
F4140 963652010500S FUSE 1.6A/250V E2,E1C N751501601160S
z
F4141 963652010520S FUSE T6.3A/250V E3 N751506301160S
z
F4141 963652010910S FUSE T3.15A/250V E2,E1C N751503151160S
JK4000 963643010360S TER, BOARD 6P JB-602A-02 G613602A0200YS
JK4001 963646001690S TER, BOARD 8P MST-108V1 G614108V1010MS
z
JK4140 963641011240S SOCKET,POWER AC (INLET JACK) G4300152P0001S
JP4140,4141 nsp JUMPER (0.6/52MM) L045084006040S
L4000-4006 nsp SP-2507 1.0 PI*2UEW TURNS D330900001330S
z
L4140 963111100420D COIL,LINE FILTER SQ2014 27mH D320201405510S
RLY4000 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
RLY4001-4004 963682100280D RELAY JZC-42F/012-2HST G680060103010S
z
RLY4140 963682100290D RELAY JZC-36FD/005-HLT G680060103030S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
