Denon AVR-2313 User Manual

211
Ref. No. Part No. Part Name Remarks Q'ty New
OTHERS PARTS GROUP
BKT4700 nsp BRACKET 0.8t/SCREW 4010210196100S
BKT4703 nsp BRACKET SCREW 4010210196000S
CLAMP460,461 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN4600,4601 nsp
CN,WAFER,I9C125Z2-09 9P BtoB
SOCKET(FEMALE) P=1.25MM
L109012520920S
CN4618 nsp CN,WIRE 2MM,I9CN,WIRE 2MM L002800112620S
CN4700 nsp
CN,WAFER,I9C125Z2-09 9P BtoB
SOCKET(FEMALE) P=1.25MM
L109012520920S
CN4701 nsp
CN,WAFER,I9C125Z2-13 13P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521320S
CN4702 nsp
CN,WAFER,I9C125Z2-07 7P BtoB
SOCKET(FEMALE) P=1.25MM
L109012520720S
CN4800 nsp CN,WIRE 2MM,I9CN,WIRE 2MM L002181040090S
CN5005 nsp
CN,WAFER,I9C125Z2-19 19P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521920S
CP3401 nsp CN,WAFER C125Z1-13 13P L109012511320S
CP3402 nsp CN,WAFER C125Z1-07 7P L109012510720S
CP3403 nsp
CN.WAFER ,I9C125Z1-33 33P BtoB
HEADER(MALE) P=1.25MM
L109012513320S
CP3404 nsp CN,WAFER C125Z1-17 17P L109012511720S
CP3406 nsp CN,WAFER C125Z1-11 11P L109012511120S
CP3407 nsp CN,WAFER C125Z1-13 13P L109012511320S
CP4600,4601 nsp CN,WAFER C125Z1-09 9P L109012510920S
CP4602 nsp CN.WAFER 2.5MM 8P L102526808010S
CP4603 nsp CN,WAFER C125Z1-11 11P L109012511120S
CP4604 nsp CN,WAFER C125Z1-17 17P L109012511720S
CP4605 nsp CN,WAFER C125Z1-15 15P L109012511520S
CP4608 nsp CN,WAFER C125Z1-09 9P L109012510920S
CP4612 nsp
CN,WAFER,I9C125Z1-27 27P BtoB
HEADER(MALE) P=1.25MM
L109012512720S
CP4613 nsp CN,WAFER C125Z1-13 13P L109012511320S
CP4614,4615 nsp CN,WAFER C125Z1-07 7P L109012510720S
CP4617 nsp
CN.WAFER ,I9C125Z1-33 33P BtoB
HEADER(MALE) P=1.25MM
L109012513320S
CP4618 nsp CN.WAFER 11P L101200101120S
CP4700 nsp CN,WAFER C125Z1-09 9P L109012510920S
CP4701 nsp CN,WAFER C125Z1-13 13P L109012511320S
CP4702 nsp CN,WAFER C125Z1-07 7P L109012510720S
z
F4600 963652500220S
FUSE GLASS TUBE 20MM,I9T2.5A/250V-
IVBSUCPCcUR S506
N751502501160S *
z
F4601-4604 963652010910S FUSE T3.15A/250V N751503151160S
JACK4700 00D9630325606 JACK,D3.5 EARPHONE G40130802001YS
JACK4702 00D2051305008 CN.WAFER 9P L103090090030S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
