Denon AVR-2313 User Manual

213
Ref. No. Part No. Part Name Remarks Q'ty New
C4431,4432 nsp C,FILM 0.1UF-J/100V D02010406C060S
C4433,4434 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C4436 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C4437 nsp C,CERAMIC COG82PF-J/50V D010820167160S
C4438 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C4439 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4440 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C4441,4442 nsp C,CERAMIC 470PF-J/50V D010471167160S
C4443 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4444 nsp C,CERAMIC 100PF-J/50V D010101167160S
C4445 nsp C,CERAMIC 470PF-J/50V D010471167160S
C4447 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C4448 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4449 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C4450 nsp C,CERAMIC 470PF-J/50V D010471167160S
C4452 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C4453,4454 00D2544573981 C,ELECT 10UF-M/50V D040100087070S
C4455,4456 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C4457,4458 nsp C,CERAMIC 330PF-J/50V D010331167160S
C4459,4460 nsp C,FILM ST-0.01UF-J/100V D02010306C060S
C4461 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C4462 nsp C,FILM 0.1UF-J/100V D02010406C060S
C4463 nsp C,FILM 0.047UF-J/100V D02047306C060S
C4464 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C4465,4466 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4467 nsp C,CERAMIC0.047UF-K/25V D011473774161S
C4470 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C4471 nsp C,ELECT 220UF-M/6.3V D040221081070S
C4472 nsp C,CERAMIC 0.001UF-J/50V D010102167160S
C4475-4478 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C4479 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
OTHERS PARTS GROUP
BD4400 nsp COIL,BEAD CBW160808U121T D340160811210S
BD4401-4410 nsp CHIP RES. 0-J 1/16W-1608REEL C20000006M160S
BD4411 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
BKT4400 nsp BRACKET 0.8t/SCREW 4010210196100S
CB4400,4401 nsp CHIP RES. 0-J 1/16W-1608REEL C20000006M160S
CLAMP401 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP403 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP405,406 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN4400 nsp CN.FPC 1.0MM 1.0-11S-40PW 40P L130100114050S
CN4402 nsp CN,WIRE 2MM,I9610MM/5P L002611050010S
CP4400 nsp CN.WAFER 5268-07A 7P L102526800700S
CP4401 nsp CN.WAFER 7P L101100030710S
CP4402,4403 nsp CN.WAFER 7P L101100040710S
CP4405 nsp CN.WAFER 7P L101100030710S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
