Denon AVR-2313 User Manual

221
Ref. No. Part No. Part Name Remarks Q'ty New
Q3203 943214500020S TR 2SC 2SC3052 J522305200050S
Q3204 963212500030S TR 2SA ISA1530AC1 J520015301210S
Q3205,3206 943214500020S TR 2SC 2SC3052 J522305200050S
Q3207 963212500030S TR 2SA ISA1530AC1 J520015301210S
Q3208 943214500020S TR 2SC 2SC3052 J522305200050S
Q3209 943216500020S TR 2SC RT1N141C J522101411210S
Q3210 943214500020S TR 2SC 2SC3052 J522305200050S
Q3211 943216500020S TR 2SC RT1N141C J522101411210S
Q3212 943214500020S TR 2SC 2SC3052 J522305200050S
Q3213-3216 943216500020S TR 2SC RT1N141C J522101411210S
Q3217 943214500020S TR 2SC 2SC3052 J522305200050S
Q3218,3219 943216500020S TR 2SC RT1N141C J522101411210S
Q3220 943214500020S TR 2SC 2SC3052 J522305200050S
Q3601-3605 943216500050S TR 2SC RT1N441C J522104411210S
Q3606,3607 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U J521051401010S
Q3608-3612 963219004200S CHIP FDC608PZ P-CH J543608000010S
Q3613 943216500020S TR 2SC RT1N141C J522101411210S
Q3614 943216500050S TR 2SC RT1N441C J522104411210S
Q3615-3618 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U J521051401010S
Q3620 963211500160D SEMI,CHIP TR/PNP 2SB PBSS5140U J521051401010S
Q3621-3624 943216500020S TR 2SC RT1N141C J522101411210S
Q3626 943216500020S TR 2SC RT1N141C J522101411210S
Q3627 943214500020S TR 2SC 2SC3052 J522305200050S
D1001 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G K125521305230S
D1313 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G K125521305230S
D1801 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
D2401 00D2760739907 D,SWITCHING CHIP KDS181S(B)-THICK K005018100040S
D3001 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G K125521305230S
D3002 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
D3006 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G K125521305230S
D3201 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
D3401 963204500220D D,SCHOTTKY CHIP LRB521S-30T1G K125521305230S
D3602 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST K005041480230S
RESISTORS GROUP
R1001-1004 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R1005-1008 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1009-1012 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R1017,1018 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1019-1021 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1024-1032 nsp R,CHIP THICK 4.7K-J,1/16W C20004726M101S
R1033,1034 nsp R,CHIP 33-J, 1/16W C20003306M101S
R1036 nsp CHIP RES. 1KJ 1/16W1005REEL C20001026M101S
R1037 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1039 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1041 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1043 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1045 nsp R,CHIP 10K-J,1/16W C20001036M111S
R1202 nsp R,CHIP 0-J,1/16W C20000006M101S
R1204 nsp R,CHIP 0-J,1/16W C20000006M101S
R1205 nsp CHIP RES. 47KJ 1/16W1005REEL C20004736M101S
R1207,1208 nsp R,CHIP 0-J,1/16W C20000006M101S
R1210,1211 nsp CHIP RES. 2.2K-J 1/16W-1005REEL C20002226M101S
R1352 nsp R,CHIP THICK,I9470-D,1/16W-1608REEL C20004711M160S
R1617,1618 nsp R,CHIP THICK 1K-D,1/16W-1608REEL C20001021M160S
R1619,1620 nsp R,CHIP THICK,I9470-D,1/16W-1608REEL C20004711M160S
R1628 nsp R,CHIP THICK,I92.7K-F,1/16W-1608REEL C20002724M161S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
