Page #227 background image
227
Ref. No. Part No. Part Name Remarks Q'ty New
C2252-2254 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2256 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2401-2405 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2406 nsp
C,CERAMIC 2.2UF-M/6.3V-1005REEL
D011225581100S
C2407 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2408 nsp
C,CERAMIC 1UF-K/10V
D011105772161S
C2409,2410 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2411 nsp
C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C2412 nsp
C,CERAMIC 2.2UF-M/6.3V-1005REEL
D011225581100S
C2413 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2415,2416 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2417 nsp
C,CERAMIC 1UF-K/10V
D011105772161S
C2418 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2419 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2420,2421 nsp
C,CERAMIC 1UF-K/10V
D011105772161S
C2422-2425 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2426 00D9630338606
C,ELECT 10UF-MVG/16V
D050100083470S
C2427-2432 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2435,2436 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2437,2438 nsp
C,CERAMIC 2200PF-K/50V
D011222777160S
C2439-2445 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2447 nsp
C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C2448 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2450 nsp
C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C2451 963134000450S
C,ELECT 100UF-MVG/16V
D050101083660S
C2454-2461 nsp
C,CERAMIC X7R3900PF-K/50V
D011392777160S
C2465-2468 nsp
C,CERAMIC 680pF-J 50V
D010681167160S
C2469,2470 nsp
C,CERAMIC 470PF-J/50V
D010471167160S
C2471-2476 nsp
C,CERAMIC 680pF-J 50V
D010681167160S
C2477,2478 nsp
C,CERAMIC 470PF-J/50V
D010471167160S
C2479,2480 nsp
C,CERAMIC 680pF-J 50V
D010681167160S
C2481,2482 00D9630338606
C,ELECT 10UF-MVG/16V
D050100083470S
C2483,2484 nsp
C,CERAMIC0.01UF-K/50V
D011103777160S
C2486 963134000450S
C,ELECT 100UF-MVG/16V
D050101083660S
C2488 963134000450S
C,ELECT 100UF-MVG/16V
D050101083660S
C2601 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2602,2603 nsp
C,CERAMIC 12PF-J/50V
D011120167101S
C2605-2608 nsp
C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C2609-2619 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2620-2622 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2623 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2624 nsp
C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C2627-2630 nsp
C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C2631-2640 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2641-2643 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2645 nsp
C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C2648 nsp
C,CERAMIC 4.7UF-K/6.3V
D011475571160S
C2652,2653 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2657 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2659 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2660-2667 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2676,2677 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2678 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2679,2680 nsp
C,CERAMIC 1000PF-K/50V
D011102177101S
C2801 nsp
C,CERAMIC 0.022UF-K/25V
D011223777160S
C2803 nsp
C,CERAMIC 1UF-K/10V
D011105772161S
C2806 nsp
C,CERAMIC 0.1UF-K/50V
D011104177101S
C2807,2808 nsp
C,CERAMIC 10PF-D/50V
D011100117101S
C2811 nsp
C,CERAMIC 1UF-K/10V
D011105772161S
