Denon AVR-2313 User Manual

230
Ref. No. Part No. Part Name Remarks Q'ty New
N3404 nsp
CN,WAFER,I9C125Z2-17 17P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521720S
N3405 nsp CN.WAFER 5P 20010-05 L101200100510S
N3406 nsp
CN,WAFER,I9C125Z2-11 11P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521120S
N3407 nsp
CN,WAFER,I9C125Z2-13 13P BtoB
SOCKET(FEMALE) P=1.25MM
L109012521320S
N3408 nsp CN.FPC 40P 10022HS-40C L130100220400S
N3601 nsp CN.WAFER 5P SMW250-5P L102050010040S
RA1003-1010 nsp R,NETWORK A-TYPE 0-J*2 1/16W C180000022100S
RLY1801 943682100250S
RELAY,I9BC1-5S-R DC5V SMT SINGLE-
SIDE STABLE RELAY
G680050202020S
X1301 141810045507S CRYSTAL CHIP FCX-04(27MHz) E80527R000080S
X1601 141810045507S CRYSTAL CHIP FCX-04(27MHz) E80527R000080S
X2001 141810050509S
CRYSTAL CHIP,I9FCX-04(25MHz) CL=7PF
SMD3225 RIVER
E80525R000080S
X2202 141810046500S CRYSTAL CHIP FCX-04(24.576MHz) E80524R576080S
X2601 141810049509S CRYSTAL CHIP FCX-04(24MHz) E80524R000080S
X3001 00D3991038900 CRYSTAL CHIP FCX-03(12MHz) E805120000020S
nsp BRACKET HDMI FRONT 4010215496000S

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
