Denon AVR-2313 User Manual

90
YES
YES
YES
YES
Check TV
(11) Is the TV HDCP-compatible?
(16) Is the set's input set to HDMI?
Do the output settings on the set match those on TV?
(13) Is the TV's input set to HDMI?
(14) Are the picture and sound output when a different TV is used?
Check set (AVR-2313)
(12) Is the TV compatible with resolutions of 1080P?
Use an HDCP-compatible TV. PC TVs cannot
be used.
Check the set's input & output setting, referring
to the set's operating instructions.
Check the TV's input setting, referring to the
TV's operating instructions.
The TV is defective.
If the TV is not compatible with resolutions of
1080P, no picture will be output, even if the
BD/DVD player resolution is set to 1080P.
NO
NO
NO
NO
NO
YES
YES
NO
YES
The set does not recognize the TV.
(MONITOR OUT: set MONITOR2)
(18) Is TP [HPD-OUT2] set to the "H"(3V-5V)?
With the TV connected,check the voltage
of the IC on the side on which the TV is
connected.
Is communication waveform conrmed in
TP[CLK_OUT2/DATA_OUT2]?
Is D1603-D1610 terminated by the TMDS
signal of 3.3V and is the signal output?
The set does not recognize the TV. (MONITOR OUT: set MONITOR1)
(17) Is TP [HPD-OUT1] set to the "H"(3V-5V)?
With the TV connected,check the voltage of the IC on the side on
which the TV is connected.
Is communication waveform conrmed in TP[CLK_OUT1/DATA_
OUT1]?
Is D1814-D1821 terminated by the TMDS signal of 3.3V and is
the signal output?
The pattern and circuit from the HDMI
connector (N1602/N1802) to the U1601 are
defective, or HDMI output circuitry is defective
(U1601 and surrounding circuitry).
The pattern and circuit from the HDMI
connector (N1802) to the U1601 are defective,
or HDMI output circuitry is defective (U1601
and surrounding circuitry).
NO
(15) Is any PIN of the HDMI connector bent or is dust adhering to the
connector?
Malfunction of the HDMI connector.
(If dust is adhering, remove the dust and
perform the troubleshooting again from (1).)
YES
NO
Is a contact part of HDMI connector normal? (Refer to 92 page(*1).)
The HDMI connector is defective.
Replace the new HDMI connector.
NO
YES

Denon AVR-2313 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	6
Composite video in	4
USB ports quantity	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Wi-Fi	No
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Optical drive included	-
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Volume control	Digital
Apple docking compatibility	iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC
Audio formats supported	FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	10900 g
