Denon AVR-2802 Service Manual

26
AVR-2802/982
R1
R2
PNP Type
NPN Type
DTA114TK
10kohm
10kohm
DTA144EK
47kohm
47kohm
DTC114EK
DTC144EK
DTC323TK 2.2kohm
-
2SA1505Y
2SC2412K (S)
2SD601A
KTC2875B
R1
R2
10kohm
10kohm
47kohm
47kohm
DTA114EK
10kohm
-
2SA970 (BL)
2SA988 (E/F)
2SA933S (S)
2SA1145 (O/Y)
2SC1740S (S)
2SC2705 (O/Y)
2SC3311A
2SD2144STPU
KTA1266 (GR)
KTC2874B
2SC/KTC3200(BL)
&
TRANSISTORS
2SB/KTB778 (R/O) 2SK771
DTC114ES
DTA114EK
DTA114TK
DTA144EK
DTC114EK
DTC143EK
DTC144EK
DTC323TK
DTA114TK
DTA114EK
DTA144EK
DTC114EK
DTC114ES
DTC143EK
DTC144EK
DTC323TK
MP15P MN15N
ESCDB
B
D
C
E
S
R:70
W
Typ.
RE:0.22
W
Typ.
BDCSE
B
D
C
E
S
R:70
W
Typ.
RE:0.22
W
Typ.
&
DIODES (included LED)
1SR35-400A
1SS270A
RB721Q-40
2
3
1
HZS3C-2
HZS5C-1
HZS6A-1
HZS6A-2
HZS7B-2
HZS9B-1
HZS33-2
MTZJ18A
S4VB20
S4VB20F
SEL1210S (Red)
SEL1410E (Green)
DAN202K
1: Anode
2: Anode
3: Cathode
FRONT
VIEW
B
C
E
FRONT
VIEW
B
C
E
TOP
VIEW
D
S
G
FRONT
VIEW
B
C
E
FRONT
VIEW
FRONT
VIEW
TOP
VIEW
E
B
C
TOP
VIEW
E
B
C
TOP
VIEW
1
2
3
TOP VIEW
TOP VIEW
2
3
1
DAP202K
1: Cathode
2: Cathode
3: Anode
TOP
VIEW
1
2
3
DTC143EK
4.7kohm
4.7kohm
DTC114ES
10kohm
10kohm

Denon AVR-2802 Specifications

General

Impedance	8 ohms
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
AM/FM Tuner	Yes
Remote Control	Yes
Number of Channels	6.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Power Output	90 W per channel (8 ohms, 20 Hz-20 kHz, 0.05% THD)
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Signal To Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Inputs	8 Analog Audio (including Phono), 5 Digital Audio (3 Optical, 2 Coaxial)
