AVR-2802/982

Ref. No. Part No. Part Name Remarks

Q'ty

Ref. No. Part No. Part Name Remarks

S751 212 4810 006 Slide switch For E1,E1H 1

S801 212 0373 000 Rotary encoder EC16B 1

S802,803 212 5611 903 Tact switch 2

S804 212 5611 903 Tact switch 1

S805 212 5611 903 Tact switch 1

SW901 212 0420 005 1P push switch (non lock) For EU,982,EC 1

T501 233 6073 107 Power trans. (Mini)-E3

For EU,982,EC,EUT

233 6058 025 Power trans. (Mini)-E2 For E2 1

233 6278 009 Power trans. (Mini)-E1 For E1,E1H 1

233 6317 009 Power trans For E1C 1

TP101-103 205 0190 049 4P NH connector base 3

TP501 205 0190 036 3P NH connector base

For EU,982,EC,

E1,E1H,E1C,EUT

W712 203 0526 002 1P contact ass'y 1

W751 203 0702 004 1P SIN-SIN wire(WHT) 1

W752 203 0702 017 1P SIN-SIN wire(RED) 1

W753 203 0702 020 1P SIN-SIN wire(YEW) 1

W755 203 0699 036 1P SIN-SIN wire(GRY) 1

W756 203 0702 033 1P SIN-SIN wire(ORG) 1

W757 203 0702 046 1P SIN-SIN wire(BLU) 1

203 5220 002 3P VH connector cord For E1,E1H 1

203 8505 009 5P VH connector cord For E1,E1H 1

513 2585 045 Fuse label

For F1 For E2,E1C

513 2654 057 Fuse label

For F1 For E1,E1H

513 2585 074 Fuse label

For F8 For E2,E1,E1H

1U-3369 EXT. IN UNIT ASS'Y

SEMICONDUCTORS GROUP

IC102 262 2616 003 IC TC9184AP

IC103 263 0896 909 IC NJM2068MD

IC301,302 263 0896 909 IC NJM2068MD

IC308-310 263 0896 909 IC NJM2068MD

IC312 262 2919 001 IC TC9274N-017

IC501-503 269 0194 007

Optical connector GP1FA551RZ

IC504 262 1205 907 IC TC74HCU04AF

IC505,506 262 2386 906 IC SN74HC151NS

IC701 263 0896 909 IC NJM2068MD

IC707 269 0187 001

Optical connector GP1FA551TZ

IC801 263 0896 909 IC NJM2068MD For EU,982,EC

263 0898 907 IC NJM5532MD

For E2,E1,E1H,E1C,EUT

IC802-804 263 0896 909 IC NJM2068MD

IC805 262 2662 002 IC TC9459N

IC809 262 2981 000 IC TC9482N

TR327,328 275 0100 902 Transistor 2SK771-5-TB

TR329 269 0054 901 Transistor DTC144EK

TR330 269 0055 900 Transistor DTA144EK

TR801-803 275 0100 902 Transistor 2SK771-5-TB

TR805 269 0083 901 Transistor DTA114EK

TR807 269 0054 901 Transistor DTC144EK

TR808 269 0083 901 Transistor DTA114EK

TR809 269 0082 902 Transistor DTC114EK

TR810 273 0460 905 Transistor KTC2875B

TR901 271 0131 924 Transistor 2SA988(E/F)

TR902 274 0160 907 Transistor 2SD2144STPU

TR903 269 0020 906

Transistor DTC114ES(10K-10K)

TR904,905 271 0131 924 Transistor 2SA988(E/F)

TR906-908 269 0083 901 Transistor DTA114EK

TR909 269 0083 901 Transistor DTA114EK

TR910 269 0083 901 Transistor DTA114EK

TR911 271 0131 924 Transistor 2SA988(E/F)

TR912 269 0083 901 Transistor DTA114EK

TR913 271 0131 924 Transistor 2SA988(E/F)

TR914 269 0082 902 Transistor DTC114EK

TR956 269 0083 901 Transistor DTA114EK

D323,324 276 0432 903 Diode 1SS270A

D701 276 0432 903 Diode 1SS270A

D801-803 276 0432 903 Diode 1SS270A

D901-910 276 0723 900 Diode RB721Q-40 For EU,982,EC
