AVR-2802/982
39
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R229,230 241 2378 920 Carbon film 220 ohm 1/4W(NB) RD14B2E221JNBST
R237-240 241 2376 964 Carbon film 47 ohm 1/4W(NB) RD14B2E470JNBST
R241-248 244 2671 956 Metal oxide 0.47 ohm 2W(NB)
RS14B3DR47JNBST(S)
R313 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R319 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R323 241 2378 920 Carbon film 220 ohm 1/4W(NB) RD14B2E221JNBST
R325 244 2671 914 Metal oxide 15 kohm 2W(NB)
RS14B3D153JNBST(S)
R327 241 2378 946 Carbon film 270 ohm 1/4W(NB) RD14B2E271JNBST
R329 241 2378 920 Carbon film 220 ohm 1/4W(NB) RD14B2E221JNBST
R337 241 2376 964 Carbon film 47 ohm 1/4W(NB) RD14B2E470JNBST
R339 241 2376 964 Carbon film 47 ohm 1/4W(NB) RD14B2E470JNBST
R341 244 2671 956 Metal oxide 0.47 ohm 2W(NB)
RS14B3DR47JNBST(S)
R343 244 2671 956 Metal oxide 0.47 ohm 2W(NB) RS14B3DR47JNBST(S)
R345 244 2671 956 Metal oxide 0.47 ohm 2W(NB) RS14B3DR47JNBST(S)
R347 244 2671 956 Metal oxide 0.47 ohm 2W(NB) RS14B3DR47JNBST(S)
R413 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R419 241 2379 987 Carbon film 1 kohm 1/4W(NB) RD14B2E102JNBST
R423 241 2378 920 Carbon film 220 ohm 1/4W(NB) RD14B2E221JNBST
R425 244 2671 914 Metal oxide 15 kohm 2W(NB)
RS14B3D153JNBST(S)
R427 241 2378 946 Carbon film 270 ohm 1/4W(NB) RD14B2E271JNBST
R429 241 2378 920 Carbon film 220 ohm 1/4W(NB) RD14B2E221JNBST
R437 241 2376 964 Carbon film 47 ohm 1/4W(NB) RD14B2E470JNBST
R439 241 2376 964 Carbon film 47 ohm 1/4W(NB) RD14B2E470JNBST
R441 244 2671 956 Metal oxide 0.47 ohm 2W(NB)
RS14B3DR47JNBST(S)
R443 244 2671 956 Metal oxide 0.47 ohm 2W(NB) RS14B3DR47JNBST(S)
R445 244 2671 956 Metal oxide 0.47 ohm 2W(NB) RS14B3DR47JNBST(S)
R447 244 2671 956 Metal oxide 0.47 ohm 2W(NB) RS14B3DR47JNBST(S)
R501 241 2387 940 Carbon film 4.7 ohm 1/4W(NB) RD14B2E4R7JNBST
R502 244 2051 961 Metal oxide 100 ohm 1W RS14B3A101JNBST(S)
R503,504 243 2039 032 Winding 0.1 ohm 5W RW99=3H0R1K
R524 242 2009 001 Composition 2.2 Mohm 1/2W
RC05GF2H225K(UL)
For EU,982,EC
R611,612 244 2671 901 Metal oxide 10 ohm 2W(NB)
RS14B3D100JNBST(S)
R630,631 244 2671 901 Metal oxide 10 ohm 2W(NB) RS14B3D100JNBST(S)
R634,635 244 2671 901 Metal oxide 10 ohm 2W(NB) RS14B3D100JNBST(S)
R713,714 244 2052 931 Metal oxide 390 ohm 1W RS14B3A391JNBST(S)
For EU,982,EC
244 2052 960 Metal oxide 220 ohm 1W
RS14B3A221JNBST(S)
For E2,E1,E1H,E1C,EUT
R715,716 244 2052 960 Metal oxide 220 ohm 1W RS14B3A221JNBST(S)
For E2,E1,E1H,E1C,EUT
VR101,102 211 6131 926 Semi fixed resistor 220 ohm V06PB221T
VR201,202 211 6131 926 Semi fixed resistor 220 ohm V06PB221T
VR301 211 6131 926 Semi fixed resistor 220 ohm V06PB221T
VR401 211 6131 926 Semi fixed resistor 220 ohm V06PB221T
CAPACITORS GROUP
C101,102 254 4538 939 Electrolytic 47 uF/16V CE04W1C470MT SMG/RE3
For EU,982,EC,E1,
E1H,E1C,EUT
254 4538 942 Electrolytic 100 uF/16V
CE04W1C101MT SMG/RE3
For E2
C103,104 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C105-108 253 1179 945 Ceramic 220 pF/50V CK45B1H221KT(DD-3)
C109,110 255 1264 908 Mylar film 1000 pF/50V CQ93M1H102JT(B)
C111,112 253 4482 901 Ceramic 33 pF/500V CC45SL2H330JT
C113,114 254 4538 942 Electrolytic 100 uF/16V
CE04W1C101MT SMG/RE3
C115,116 253 4486 907 Ceramic 47 pF/500V CC45SL2H470JT
C117,118 253 4465 902 Ceramic 5 pF/500V CC45SL2H050CT
C119,120 255 1275 942 Mylar film 220 pF/100V CQ93M2A221KT(B)
C121,122 254 4527 982 Electrolytic 10 uF/100V CE04W2A100MT SMG/RE3
C123-126 254 4527 979 Electrolytic 4.7 uF/100V CE04W2A4R7MT SMG/RE3
C201,202 254 4538 939 Electrolytic 47 uF/16V CE04W1C470MT SMG/RE3
For EU,982,EC,
E1,E1H,E1C,EUT
254 4538 942 Electrolytic 100 uF/16V
CE04W1C101MT SMG/RE3
For E2
C203,204 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C205-208 253 1179 945 Ceramic 220 pF/50V CK45B1H221KT(DD-3)
C209,210 255 1264 908 Mylar film 1000 pF/50V CQ93M1H102JT(B)
C211,212 253 4482 901 Ceramic 33 pF/500V CC45SL2H330JT
C213,214 254 4538 942 Electrolytic 100 uF/16V
CE04W1C101MT SMG/RE3
C215,216 253 4486 907 Ceramic 47 pF/500V CC45SL2H470JT
C217,218 253 4465 902 Ceramic 5 pF/500V CC45SL2H050CT
C219,220 255 1275 942 Mylar film 220 pF/100V CQ93M2A221KT(B)
C221,222 254 4527 982 Electrolytic 10 uF/100V CE04W2A100MT SMG/RE3
C223-226 254 4527 979 Electrolytic 4.7 uF/100V CE04W2A4R7MT SMG/RE3
C301 254 4538 939 Electrolytic 47 uF/16V CE04W1C470MT SMG/RE3
For EU,982,EC,E1,E1H,E1C,EUT
254 4538 942 Electrolytic 100 uF/16V CE04W1C101MT SMG/RE3
For E2
C303 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C305 253 1179 945 Ceramic 220 pF/50V CK45B1H221KT(DD-3)
C307 253 1179 945 Ceramic 220 pF/50V CK45B1H221KT(DD-3)
C309 255 1264 908 Mylar film 1000 pF/50V CQ93M1H102JT(B)
C311 253 4482 901 Ceramic 33 pF/500V CC45SL2H330JT
C313 254 4538 942 Electrolytic 100 uF/16V
CE04W1C101MT SMG/RE3
C315 253 4486 907 Ceramic 47 pF/500V CC45SL2H470JT
C317 253 4465 902 Ceramic 5 pF/500V CC45SL2H050CT
C319 255 1275 942 Mylar film 220 pF/100V CQ93M2A221KT(B)
C321 254 4527 982 Electrolytic 10 uF/100V
CE04W2A100MT SMG/RE3
C323 254 4527 979 Electrolytic 4.7 uF/100V CE04W2A4R7MT SMG/RE3
C325 254 4527 979 Electrolytic 4.7 uF/100V CE04W2A4R7MT SMG/RE3

Denon AVR-2802 Specifications

General

Impedance	8 ohms
Surround Sound	Dolby Digital, DTS, Dolby Pro Logic II
AM/FM Tuner	Yes
Remote Control	Yes
Number of Channels	6.1
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Power Output	90 W per channel (8 ohms, 20 Hz-20 kHz, 0.05% THD)
Video Inputs	Composite, S-Video
Video Outputs	Composite, S-Video
Signal To Noise Ratio	98 dB
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Inputs	8 Analog Audio (including Phono), 5 Digital Audio (3 Optical, 2 Coaxial)
