AVR-2802/982
45
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C896,897 254 4525 900 Electrolytic 33 uF/50V
CE04W1H330MT SMG/RE3
For EU,982,EC
254 4541 942 Electrolytic 100 uF/25V
CE04W1E101MT SMG/RE3
For E2
254 4541 939 Electrolytic 47 uF/25V
CE04W1E470MT SMG/RE3
For E1,E1H,E1C,EUT
C901 253 1181 904 Ceramic 0.01 uF/50V
CK45F1H103ZT(DD-3)
C902 254 4524 956 Electrolytic 2.2 uF/50V
CE04W1H2R2MT SMG/RE3
C903 253 1181 904 Ceramic 0.01 uF/50V
CK45F1H103ZT(DD-3)
C909 254 4524 943 Electrolytic 1 uF/50V
CE04W1H010MT SMG/RE3
C911 254 4527 908 Electrolytic 0.1 uF/100V
CE04W2A0R1MT SMG/RE3
C912 254 4524 985 Electrolytic 10 uF/50V
CE04W1H100MT SMG/RE3
C913,914 254 4524 901 Electrolytic 0.1 uF/50V
CE04W1H0R1MT SMG/RE3
C915 254 4524 901 Electrolytic 0.1 uF/50V
CE04W1H0R1MT SMG/RE3
C916-918 254 4524 901 Electrolytic 0.1 uF/50V
CE04W1H0R1MT SMG/RE3
C919 254 4522 958 Electrolytic 100 uF/35V
CE04W1V101MT SMG/RE3
C964 254 4524 901 Electrolytic 0.1 uF/50V
CE04W1H0R1MT SMG/RE3
OTHER PARTS GROUP
Q'ty
CW094 205 0885 037 9P connector socket (TUC-P) 1
CW102,103 205 0885 053 10P connector socket (TUC-P) 2
CW113-116 205 1092 023 11P connector plug (TWG-P) 4
CW119 205 0885 066 11P connector socket (TUC-P) 1
CW124 205 0885 079 12P connector socket (TUC-P) 1
CW131,132 205 1092 036 13P connector plug (TWG-P) 2
CW152 205 0885 040 15P connector socket (TUC-P) 1
CW191,192 205 1092 007 19P connector plug (TWG-P) 2
CX045 205 0884 083 4P connector base (TUC-P) 1
CX115 205 1091 024 11P connector base (TWG-P) 1
CX125 205 0884 070 12P connector base (TUC-P) 1
CX132 205 1091 037 13P connector base (TWG-P) 1
FB504-508 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 5
FB701 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT 1
JK301 204 8513 010 6P pin jack (S-GND) 1
JK701 204 8545 004 4P pin jack (GND) 1
JK702 204 8593 001 1P pin jack (OR,NI) 1
L502 235 0060 918 Inductor 4.7uH 1
L503 235 0060 905 Inductor 2.2uH 1
L504,505 235 0060 918 Inductor 4.7uH 2
L701,702 235 9003 002 FTZ choke coil For E2,EUT 2
RL901 214 0203 008 Relay (NA12W-K) 1
W708,709 205 1034 010 M3 Screw terminal 2
W726 203 0525 003 1P SIN cord Ass'y 1
W731 203 0463 000 1P SIN con. Ass'y 1
1U-3370 CONTROL UNIT ASS'Y
SEMICONDUCTORS GROUP
IC101 262 2549 002 IC LC75721E
IC102 499 0290 007 Remote sensor GP1U271X
IC103 262 2745 903 IC BU2090F
IC105 262 2547 907 IC LC72720NM For E2
IC303 262 2982 009 IC TMP88CU74F
IC304,305 263 1040 903 IC BU4094BCF
TR111 269 0083 901 Transistor DTA114EK
TR112 269 0055 900 Transistor DTA144EK
TR113-115 269 0054 901 Transistor DTC144EK
TR116,117 269 0055 900 Transistor DTA144EK
TR118 269 0082 902 Transistor DTC114EK
TR301 274 0163 904 Transistor 2SD601A
TR302 271 0299 905 Transistor 2SA933S(S)
TR303 269 0054 901 Transistor DTC144EK
TR304 269 0082 902 Transistor DTC114EK
TR305 269 0055 900 Transistor DTA144EK
TR306 269 0054 901 Transistor DTC144EK
TR307 269 0083 901 Transistor DTA114EK
TR308,309 269 0054 901 Transistor DTC144EK
TR401 269 0082 902 Transistor DTC114EK
TR402 269 0086 908 Transistor DTA114TK
TR403,404 269 0066 902 Transistor DTC323TK
TR405 269 0082 902 Transistor DTC114EK
TR406 273 0384 900 Transistor 2SC2412K(S) For E2
D104 276 0468 906 Zener diode HZS9B-1TD
D109-111 276 0432 903 Diode 1SS270A
D302 276 0432 903 Diode 1SS270A
D303 276 0454 910 Zener diode HZS3C-2TD
D304 276 0432 903 Diode 1SS270A
D305,306 276 0704 903 Diode 1SR35-400A(T93X)
D401 276 0432 903 Diode 1SS270A
LD102-107 393 9434 906 LED SEL1210S
LD109,110 393 9434 906 LED SEL1210S
LD113,114 393 9452 904 LED SEL1410E
RESISTORS GROUP
R101 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R102,103 247 2006 960 Carbon chip 470 ohm 1/16W RM73B--471JT
R104-107 247 2007 927 Carbon chip 820 ohm 1/16W RM73B--821JT
R109,110 247 2007 927 Carbon chip 820 ohm 1/16W RM73B--821JT
R111 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R112 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R113 247 2005 974 Carbon chip 200 ohm 1/16W RM73B--201JT
To Next Page
