Denon AVR-2803 Operating Instructions

36
ENGLISH
Manual tuning
1
Set the input function to “TUNER”.
FUNCTION
(Main unit) (Remote control unit)
2
Watching the display, press
the BAND button to select
the desired band (AM or
FM).
(Remote control unit)
3
Press the MODE button to
set the manual tuning mode.
Check that the display’s
“AUTO” indicator turns off.
(Remote control unit)
4
Press the TUNING + (up) or –
(down) button to tune in the
desired station.
The frequency changes
continuously
when the
button is held in.
(Remote control unit)
NOTES:
• When in the auto tuning mode on the FM band, the
“STEREO” indicator lights on the display when a
stereo broadcast is tuned in. At open frequencies,
the noise is muted and the “TUNED” and
“STEREO” indicators turn off.
• When the manual tuning mode is set, FM stereo
broadcasts are received in monaural and the
“STEREO” indicator turns off.
Preset memory
2, 5
3
4
1
Use the “Auto tuning” or “Manual tuning”
operation to tune in the station to be preset in
the memory.
2
Press the MEMORY button.
(Remote control unit)
3
Press the SHIFT button and
select the desired memory
block (A to E).
(Remote control unit)
5
Press the MEMORY button
again to store the station in
the preset memory.
(Remote control unit)
To preset other channels, repeat steps 2 to 5.
A total of 40 broadcast stations can be preset
— 8 stations (channels 1 to 8) in each of blocks
A to E.
4
Press the CHANNEL + (up)
or – (down) button to select
the desired preset channel (1
to 8).
(Remote control unit)
Checking the preset stations
1
Press the ON SCREEN/DISPLAY button repeatedly until the “Tuner Preset
Stations” screen appears on the on screen display.
(Remote control unit)
• The preset (broadcast) stations can be checked on the on screen display (OSD).
1
Recalling preset stations
1
2
•To call out preset stations from the remote control unit.
1
Watching the display, press
the SHIFT button to select
the preset memory block.
(Remote control unit)
2
Watching the display, press
the CHANNEL + (up) or –
(down) button to select the
desired preset channel.
(Remote control unit)
21
• Calling out preset stations from the main unit‘s panel.
1
Press the TUNING PRESET
button.
(Main unit)
2
Turn the FUNCTION knob
and select the desired
station.
FUNCTION
(Main unit)

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
