Denon AVR-2803 Service Manual

55
55
AVR-2803/983/AVC-2870
D605 276 0305 001 S4VB20
D606,607 276 0432 903 1SS270A TE (TAPE)
D608 276 0305 001 S4VB20
D612 276 0747 902 RB441Q-40T-77
ZD601,602 276 0477 926 HZS16-3TD
ZD603 276 0474 903 HZS12B-1TD
ZD604,605 276 0463 901 HZS6C-1TD
PT601 279 0034 067 PTH9M04BB222TS2F333
RESISTORS GROUP
R127,128 241 2379 987 RD14B2E102JNBST
R133,134 241 2379 987 RD14B2E102JNBST
R137,138 244 2671 914 RS14B3D153JNBST(S)
R139,140 241 2378 920 RD14B2E221JNBST
R141,142 241 2378 946 RD14B2E271JNBST
R143,144 241 2378 920 RD14B2E221JNBST
R227 241 2379 987 RD14B2E102JNBST
R233 241 2379 987 RD14B2E102JNBST
R237 244 2671 914 RS14B3D153JNBST(S)
R239 241 2378 920 RD14B2E221JNBST
R241 241 2378 946 RD14B2E271JNBST
R243 241 2378 920 RD14B2E221JNBST
R327,328 241 2379 987 RD14B2E102JNBST
R333,334 241 2379 987 RD14B2E102JNBST
R337,338 244 2671 914 RS14B3D153JNBST(S)
R339,340 241 2378 920 RD14B2E221JNBST
R341,342 241 2378 946 RD14B2E271JNBST
R343,344 241 2378 920 RD14B2E221JNBST
R427,428 241 2379 987 RD14B2E102JNBST
R433,434 241 2379 987 RD14B2E102JNBST
R437,438 244 2671 914 RS14B3D153JNBST(S)
R439,440 241 2378 920 RD14B2E221JNBST
R441,442 241 2378 946 RD14B2E271JNBST
R443,444 241 2378 920 RD14B2E221JNBST
R603 241 2376 919 RD14B2E300JNBST
R623,624 241 2376 919 RD14B2E300JNBST
R626 244 2052 931 RS14B3A391JNBST(S)
CAPACITORS GROUP
C107,108 254 4538 939 CE04W1C470MT SMG/RE3
C109,110 254 4524 985 CE04W1H100MT SMG/RE3
C111,112 255 1273 944 CQ93M1H221KT(B)
C113,114 255 1273 986 CQ93M1H471JT(B)
C115,116 255 1264 966 CQ93M1H332JT(B)
C117,118 254 4538 955 CE04W1C221MT SMG/RE3
C119,120 253 4482 901 CC45SL2H330JT
C121,122 253 4465 902 CC45SL2H050CT
C123,124 253 4486 907 CC45SL2H470JT
C125,126 255 1275 942 CQ93M2A221KT(B)
C207 254 4538 939 CE04W1C470MT SMG/RE3
C209 254 4524 985 CE04W1H100MT SMG/RE3
C211 255 1273 944 CQ93M1H221KT(B)
C213 255 1273 986 CQ93M1H471JT(B)
C215 255 1264 966 CQ93M1H332JT(B)
C217 254 4538 955 CE04W1C221MT SMG/RE3
C219 253 4482 901 CC45SL2H330JT
C221 253 4465 902 CC45SL2H050CT
C223 253 4486 907 CC45SL2H470JT
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
