Denon AVR-2803 Service Manual

56
56
AVR-2803/983/AVC-2870
C225 255 1275 942 CQ93M2A221KT(B)
C307,308 254 4538 939 CE04W1C470MT SMG/RE3
C309,310 254 4524 985 CE04W1H100MT SMG/RE3
C311,312 255 1273 944 CQ93M1H221KT(B)
C313,314 255 1273 986 CQ93M1H471JT(B)
C315,316 255 1264 966 CQ93M1H332JT(B)
C317,318 254 4538 955 CE04W1C221MT SMG/RE3
C319,320 253 4482 901 CC45SL2H330JT
C321,322 253 4465 902 CC45SL2H050CT
C323,324 253 4486 907 CC45SL2H470JT
C325,326 255 1275 942 CQ93M2A221KT(B)
C407,408 254 4538 939 CE04W1C470MT SMG/RE3
C409,410 254 4524 985 CE04W1H100MT SMG/RE3
C411,412 255 1273 944 CQ93M1H221KT(B)
C413,414 255 1273 986 CQ93M1H471JT(B)
C415,416 255 1264 966 CQ93M1H332JT(B)
C417,418 254 4538 955 CE04W1C221MT SMG/RE3
C419,420 253 4482 901 CC45SL2H330JT
C421,422 253 4465 902 CC45SL2H050CT
C423,424 253 4486 907 CC45SL2H470JT
C425,426 255 1275 942 CQ93M2A221KT(B)
C525 253 8022 707 CK45F2EAC103MC
C599 254 4586 949 CE04W2A100MT(RE3)
C601-604 256 1058 971 CF93A1H104JT (JL)
C605,606 256 1042 903 CF93A2E104KT
C607 254 4541 939 CE04W1E470MT SMG/RE3
C608 254 4524 969 CE04W1H3R3MT SMG/RE3
C609 254 4524 943 CE04W1H010MT SMG/RE3
C610 254 6233 708 CE04W1C183MC(SMQ)
C611 256 1042 903 CF93A2E104KT
C613,614 254 4524 943 CE04W1H010MT SMG/RE3
C617 254 4403 734 CE04W1E472MC(SMG)
C618 254 4542 718 CE04W1E332MC SMG/RE3
C619,620 254 4524 943 CE04W1H010MT SMG/RE3
C622 254 4541 939 CE04W1E470MT SMG/RE3
C623 254 4541 942 CE04W1E101MT SMG/RE3
C625 254 4524 943 CE04W1H010MT SMG/RE3
C626,627 254 4579 707 CE04W1H221MC(RE3)
C628,629 254 4524 985 CE04W1H100MT SMG/RE3
C630,631 254 6235 706 CE68W1V682M *
C636 254 4538 939 CE04W1C470MT SMG/RE3
C643 254 4524 901 CE04W1H0R1MT SMG/RE3
OTHER PARTS GROUP
! AC501 203 3976 002 AC OUTLET(2P) for EU,EC
CW035,036 205 0697 034 JL CONNECTOR(F-E)
CW044 205 0885 082 4P CON.SOCKET(TUC-P)
CW063-069 205 0942 019 6P CON.SOCKET(TUC-P
CW082 205 0885 095 8P CON.SOCKET(TUC-P)
CW114 205 1229 016 11P FJ CONN.PLUG
CW115 205 0885 066 11P CON.SOCKET TUC-P
CW119 205 0885 066 11P CON.SOCKET TUC-P
CW132 205 0942 006 13P CON.SOCKET(TUC-P
CW143 205 1229 029 14P FJ CONN.PLUG
CW152 205 0885 040 15P CON.SOCKET TUC-P
CX021 205 0581 069 2P VH-VH CON BASE for E2,E1,E1C,E1H,EUT,E1K
CX022 205 0581 056 2P VH CONNECTOR BASE
CX023 205 1093 006 2P VH CONNECTOR BASE for E2,E1,E1H
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
