Denon AVR-2803 Service Manual

57
57
AVR-2803/983/AVC-2870
CX024 205 0581 001 2P VH CONNECTOR BASE
CX062 205 0943 018 6P CON.BASE(TUC-P)
CX071,072 205 0943 021 7P CON.BASE(TUC-P)
CX078 205 1248 013 7P JE CON.PLUG *
CX085 205 0343 087 8P CONN.BASE(KR-PH)
CX093 205 0233 090 9P EH CONNECTOR BASE
CX111 205 0884 067 11P CON.BASE TUC-P
CX113 205 0884 067 11P CON.BASE TUC-P
CX116 205 1091 024 11P CON BASE TWG-P
CX153 205 0884 041 15P CON.BASE TUC-P
CX155 205 1248 055 15P JE CON.PLUG
CX156 205 1253 008 15P FFC CONNECTOR-FE
CX193 205 1091 008 19P CON.BASE(TWG-P)
CY021 205 0581 069 2P VH-VH CON BASE for E2,E1,E1C,E1H,EUT,E1K
! F1 206 1046 014 FUSE 8A for EU,EC
! F1 206 1015 074 FUSE 3.15A for E2,E1C,E1K
! F1 206 1036 011 FUSE (6.3A) for E1,E1H
! F8 206 1046 014 FUSE 8A for EU,EC
! F8 206 1015 032 FUSE (2.5A) for E2,E1,E1H
! F11-15 206 1039 089 FUSE 3.15A for EU,EC
! F11-13 206 1015 074 FUSE 3.15A for E2,E1,E1C,E1H,E1K
! F14,15 206 1015 032 FUSE (2.5A) for E2,E1,E1C,E1H,E1K
FF501 202 0040 909 FUSE CLIP (TAPE)
FF502 202 0040 909 FUSE CLIP (TAPE) for EU,EC,E2,E1,E1H,EUT
FF601-605 202 0040 909 FUSE CLIP (TAPE)
FH501 202 0040 909 FUSE CLIP (TAPE)
FH502 202 0040 909 FUSE CLIP (TAPE) for EU,EC,E2,E1,E1H,EUT
FH601-605 202 0040 909 FUSE CLIP (TAPE)
! RL502 214 0221 006 RELAY TV-8
! S501 212 1030 009 POWER SWITCH (TV-5) for E2,E1,E1C,E1H,EUT,E1K
ST501 205 1034 007 M3 SCREW TERMINAL for E2,E1,E1C,E1H,E1K
ST601 205 1034 010 M3 SCREW TERMINAL
415 0309 026 P.V.C. TUBE(L=20) (for PT601)
415 0299 000 CONDENSER COVER for E2,E1,E1C,E1H,E1K(for C525)
513 3730 051 FUSE LABEL(T3.15AL) for E2,E1,E1C,E1H,E1K
513 3730 048 FUSE LABEL(T2.5AL) for E2,E1,E1H
513 3730 080 FUSE LABEL(T6.3AL) for E1,E1H
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
