Denon AVR-2803 Service Manual

60
60
AVR-2803/983/AVC-2870
CAPACITORS GROUP
C101,102 257 0507 976 CC73CH1H331JT
C104-109 257 0511 904 CK73F1H103ZT
C110 257 0509 929 CK73B1H102KT
C113,114 257 0507 976 CC73CH1H331JT
C117-121 254 4524 943 CE04W1H010MT SMG/RE3
C122-129 257 0507 976 CC73CH1H331JT
C167,168 257 0507 976 CC73CH1H331JT
C169-172 257 0506 951 CC73CH1H101JT
C174 257 0511 904 CK73F1H103ZT
C177,178 257 0511 904 CK73F1H103ZT
C188 257 0509 929 CK73B1H102KT
C205,206 254 4524 969 CE04W1H3R3MT SMG/RE3
C209,210 254 4524 943 CE04W1H010MT SMG/RE3
C211,212 254 4524 998 CE04W1H220MT SMG/RE3
C213,214 254 4524 969 CE04W1H3R3MT SMG/RE3
C217,218 254 4524 943 CE04W1H010MT SMG/RE3
C219,220 254 4524 998 CE04W1H220MT SMG/RE3
C221,222 254 4538 900 CE04W1C100MT SMG/RE3
C225,226 254 4524 998 CE04W1H220MT SMG/RE3
C301,302 257 0507 976 CC73CH1H331JT
C303,304 257 0506 951 CC73CH1H101JT
C305,306 257 0507 976 CC73CH1H331JT
C309-316 257 0507 976 CC73CH1H331JT
C319,320 257 0507 934 CC73CH1H221JT
C321,322 254 4538 900 CE04W1C100MT SMG/RE3
C323 257 0506 951 CC73CH1H101JT
C324,325 254 4533 934 CE04W0J221MT SMG/RE3
C326 257 0506 951 CC73CH1H101JT
C327,328 255 4199 999 CQ92M1H243JT(MRZ)
C329,330 255 1265 907 CQ93M1H682JT(B)
C331,332 254 4538 900 CE04W1C100MT SMG/RE3
C335 257 0512 903 CK73F1E104ZT
C336 257 0509 929 CK73B1H102KT
C337 257 0512 903 CK73F1E104ZT
C339 257 0512 903 CK73F1E104ZT
C341 257 0512 903 CK73F1E104ZT
C342 254 4524 943 CE04W1H010MT SMG/RE3
C343 257 0512 903 CK73F1E104ZT
C344 254 4524 943 CE04W1H010MT SMG/RE3
C345 257 0512 903 CK73F1E104ZT
C346 254 4524 943 CE04W1H010MT SMG/RE3
C347 257 0512 903 CK73F1E104ZT
C348 254 4524 943 CE04W1H010MT SMG/RE3
C349 257 0512 903 CK73F1E104ZT
C351 254 4524 943 CE04W1H010MT SMG/RE3
C353 254 4524 943 CE04W1H010MT SMG/RE3
C361,362 254 4538 900 CE04W1C100MT SMG/RE3
C363,364 254 4524 943 CE04W1H010MT SMG/RE3
C367-370 256 1058 955 CF93A1H683JT (JL)
C371,372 254 4524 998 CE04W1H220MT SMG/RE3
C373 254 4524 985 CE04W1H100MT SMG/RE3
C374,375 254 4524 998 CE04W1H220MT SMG/RE3
C376 254 4524 985 CE04W1H100MT SMG/RE3
C377-380 254 4541 939 CE04W1E470MT SMG/RE3
C381-388 254 4524 969 CE04W1H3R3MT SMG/RE3
C389-392 257 0502 971 CC73CH1H5R0CT
C393-396 254 4524 943 CE04W1H010MT SMG/RE3
C397,398 254 4524 998 CE04W1H220MT SMG/RE3
C399 254 4524 985 CE04W1H100MT SMG/RE3
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
