Denon AVR-2803 Service Manual

61
61
AVR-2803/983/AVC-2870
C400,401 254 4524 998 CE04W1H220MT SMG/RE3
C402 254 4524 985 CE04W1H100MT SMG/RE3
C403-406 254 4541 939 CE04W1E470MT SMG/RE3
C407-414 254 4524 969 CE04W1H3R3MT SMG/RE3
C415-418 257 0502 971 CC73CH1H5R0CT
C419-422 254 4524 943 CE04W1H010MT SMG/RE3
C424-427 254 4538 900 CE04W1C100MT SMG/RE3
C432 257 0512 903 CK73F1E104ZT
C433 254 4524 943 CE04W1H010MT SMG/RE3
C453,454 257 0506 951 CC73CH1H101JT
C455,456 257 0507 976 CC73CH1H331JT
C503,504 254 4533 921 CE04W0J101MT SMG/RE3
C505-508 257 0501 901 CK73B1H103KT (1608)
C510 257 0501 901 CK73B1H103KT (1608)
C513 257 0516 954 CK73B1E104KT
C514-519 254 4524 972 CE04W1H4R7MT SMG/RE3
C521 257 0516 954 CK73B1E104KT
C522-526 257 0516 909 CK73B1E223KT
C527 257 0516 954 CK73B1E104KT
C528,529 257 0506 951 CC73CH1H101JT
C532 257 3011 919 CF73=1H102JT(ECHUB5)
C533 257 0512 903 CK73F1E104ZT
C534 257 3011 919 CF73=1H102JT(ECHUB5)
C536,537 254 4524 985 CE04W1H100MT SMG/RE3
C538 254 4538 942 CE04W1C101MT SMG/RE3
C539 254 4524 985 CE04W1H100MT SMG/RE3
C540 257 0516 954 CK73B1E104KT
C541 257 0501 901 CK73B1H103KT (1608)
C542,543 257 3011 919 CF73=1H102JT(ECHUB5)
C544 257 0516 909 CK73B1E223KT
C545 257 0509 929 CK73B1H102KT
C546 257 0516 909 CK73B1E223KT
C549 254 4538 942 CE04W1C101MT SMG/RE3
C550 256 1058 971 CF93A1H104JT (JL)
C551 257 0512 903 CK73F1E104ZT
C552 257 0509 929 CK73B1H102KT
C553 255 1264 982 CQ93M1H472JT(B)
C554 257 0512 903 CK73F1E104ZT
C555 254 4538 900 CE04W1C100MT SMG/RE3
C556 254 4525 913 CE04W1H470MT SMG/RE3
C560 257 0516 909 CK73B1E223KT
C564 254 4573 981 CE04W1H100MT(RE3)
C565 257 0506 935 CC73CH1H820JT
C570 257 0504 966 CC73CH1H390JT
C571 257 0508 962 CC73CH1H751JT
C573 257 0506 977 CC73CH1H121JT
C574,575 257 0506 993 CC73CH1H151JT
C578 257 0507 992 CC73CH1H391JT
C579 257 0508 962 CC73CH1H751JT
C580 257 0506 977 CC73CH1H121JT
C585,586 255 1273 902 CQ93M1H101KT(B)
C588 254 4525 913 CE04W1H470MT SMG/RE3
C596 257 0507 976 CC73CH1H331JT
C597,598 257 0506 993 CC73CH1H151JT
C599 257 0508 962 CC73CH1H751JT
C600 257 0508 917 CC73CH1H471JT
C601 257 0508 962 CC73CH1H751JT
C602 257 0506 993 CC73CH1H151JT
C603 257 0508 959 CC73CH1E681JT
C604 257 0506 935 CC73CH1H820JT
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
