Denon AVR-2803 Service Manual

62
62
AVR-2803/983/AVC-2870
C605 257 0503 996 CC73CH1H200JT
C606 257 0506 935 CC73CH1H820JT
C607 257 0506 906 CC73CH1H620JT
C609 257 0506 935 CC73CH1H820JT
C610 257 0506 906 CC73CH1H620JT
C611 257 0506 935 CC73CH1H820JT
C620-627 254 4573 994 CE04W1H220MT(RE3)
C628-631 254 4524 901 CE04W1H0R1MT SMG/RE3
C632,633 254 4525 913 CE04W1H470MT SMG/RE3
C634,635 254 4573 981 CE04W1H100MT(RE3)
C638 257 0508 959 CC73CH1E681JT
C639 257 0508 962 CC73CH1H751JT
C640 257 0507 992 CC73CH1H391JT
C641 257 0507 976 CC73CH1H331JT
C642,643 257 0507 992 CC73CH1H391JT
C644 257 0507 947 CC73CH1H241JT
C645 257 0507 992 CC73CH1H391JT
C646 257 0501 901 CK73B1H103KT (1608)
C801-804 257 0511 904 CK73F1H103ZT
C805 257 0501 901 CK73B1H103KT (1608)
C806 254 4533 921 CE04W0J101MT SMG/RE3
C808 254 4533 921 CE04W0J101MT SMG/RE3
C809 257 0512 903 CK73F1E104ZT
C811 257 0512 903 CK73F1E104ZT
C813,814 257 0503 983 CC73CH1H180JT
C815 257 0511 904 CK73F1H103ZT
C817 254 4368 934 CE04W1E101MT(ASF)
C818 254 4313 963 CE04W1H010MT(ASF)
C819 254 4347 748 CE04W1H010MC(ARSA)
C822 254 4368 934 CE04W1E101MT(ASF)
C823 255 1265 936 CQ93M1H103JT(B)
C990 254 4538 900 CE04W1C100MT SMG/RE3
OTHER PARTS GROUP
AS801 417 0649 009 HEAT SINK *
CW042 205 0885 082 4P CON.SOCKET(TUC-P)
CW048 205 0885 082 4P CON.SOCKET(TUC-P)
CW061 205 0942 019 6P CON.SOCKET(TUC-P
CW071,072 205 0942 022 7P CON.SOCKET(TUC-P
CW076 205 0942 022 7P CON.SOCKET(TUC-P
CW083 205 0885 095 8P CON.SOCKET(TUC-P)
CW091 205 0885 037 9P CON.SOCKET TUC-P
CW095 205 0885 037 9P CON.SOCKET TUC-P
CW102 205 0885 053 10P CON.SOCKET TUC-P
CW111-113 205 0885 066 11P CON.SOCKET TUC-P
CW151 205 0885 040 15P CON.SOCKET TUC-P
CW157 205 0885 040 15P CON.SOCKET TUC-P
CX114 205 1228 017 11P FJ CONN.BASE
CX143 205 1228 020 14P FJ CONN.BASE
CX201,202 205 1246 002 20P PIN HEADER(9142)
FB501 247 2018 903 RM73B--0R0KT
FB503 247 2018 903 RM73B--0R0KT
FB504,505 235 0130 903 CHIP EMIFIL(11A121)
FB506 247 2018 903 RM73B--0R0KT
FB511 235 0130 903 CHIP EMIFIL(11A121)
FB512,513 247 2018 903 RM73B--0R0KT
FB519 235 0049 900 BEADS INDUCTOR TAPE
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
