Denon AVR-2803 Service Manual

63
63
AVR-2803/983/AVC-2870
FB521,522 235 0049 900 BEADS INDUCTOR TAPE
FB801 235 0130 903 CHIP EMIFIL(11A121)
FB803-808 235 0130 903 CHIP EMIFIL(11A121)
JK101-103 204 8656 003 6P PIN JACK (S2GND)
JK301 204 8562 003 2P PINJACK(S-GND)
JK302 204 8656 003 6P PIN JACK (S2GND)
JK401,402 204 8545 004 4P PIN JACK(GND)
JK501 204 8658 001 2P PIN JACK(C-TYPE)
L301,302 235 9003 002 FTZ CHOKE COIL for E2,EUT
TP801 205 0343 074 7P CONN.BASE(KR-PH)
W703 203 0461 002 1P SIN CON.ASS'Y
X801 399 0624 001 X'TAL(15.0MHZ)
412 2404 069 PWB HOLDER (WLS-12)
473 7002 018 3X8 CBTS (S)-Z
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
