AVR-2803/983/AVC-2870
R327,328 244 2671 901 RS14B3D100JNBST(S)
R403-406 241 2376 964 RD14B2E470JNBST
R407-414 244 2671 956 RS14B3DR47JNBST(S)
R425,426 244 2682 903 RS14B3D010JNBST(S) *
R427,428 244 2671 901 RS14B3D100JNBST(S)
R501 241 2387 940 RD14B2E4R7JNBST
R502 244 2051 961 RS14B3A101JNBST(S)
R503,504 243 2039 032 RW99=3H0R1K
R527,528 244 2052 960 RS14B3A221JNBST(S)
R531 245 2367 920 RN14K2E152FT(5)
R534,535 244 2052 960 RS14B3A221JNBST(S)
VR101,102 211 6131 939 V06PB331T
VR201 211 6131 939 V06PB331T
VR301,302 211 6131 939 V06PB331T
VR401,402 211 6131 939 V06PB331T
CAPACITORS GROUP
C101,102 254 4313 934 CE04W1H470MT(ASF)
C103-106 254 4586 936 CE04W2A4R7MT(RE3)
C107,108 256 1058 939 CF93A1H473JT (JL)
C201 254 4481 918 CE04W2A100MT(ASF)
C203 254 4586 936 CE04W2A4R7MT(RE3)
C205 254 4586 936 CE04W2A4R7MT(RE3)
C207 256 1058 939 CF93A1H473JT (JL)
C301,302 254 4481 918 CE04W2A100MT(ASF)
C303-306 254 4586 936 CE04W2A4R7MT(RE3)
C307,308 256 1058 939 CF93A1H473JT (JL)
C401,402 254 4481 918 CE04W2A100MT(ASF)
C403-406 254 4586 936 CE04W2A4R7MT(RE3)
C407,408 256 1058 939 CF93A1H473JT (JL)
C502 254 4313 963 CE04W1H010MT(ASF)
C503,504 255 4235 057 CQ93P2A104J(NH)
C506 254 4587 715 CE04W2A101MC(RE3)
C507,508 254 6234 707 CE68W1J123M(DL) *
C516 254 4368 934 CE04W1E101MT(ASF)
C517 254 4524 943 CE04W1H010MT SMG/RE3
C522 254 4403 721 CE04W1E222MC (SMG)
C523 254 4313 963 CE04W1H010MT(ASF)
C524 256 1058 971 CF93A1H104JT (JL)
C528 255 1265 936 CQ93M1H103JT(B)
C531 255 4235 976 CQ93P2A153JT(NH)
C615 254 4573 949 CE04W1H010MT(RE3)
C616-623 254 4538 913 CE04W1C220MT SMG/RE3
C626-633 254 4573 994 CE04W1H220MT(RE3)
C637 254 4573 949 CE04W1H010MT(RE3)
OTHER PARTS GROUP
CW047 203 6365 021 4P KR-DA CONN CORD
CW062 205 0942 019 6P CON.SOCKET(TUC-P
CW153 205 0885 040 15P CON.SOCKET TUC-P
CX031 205 0343 032 3P CONN.BASE(KR-PH)
CX033 205 0825 000 3P AC CON.BASE
CX035,036 205 0696 035 JL CONNECTOR(BT-E)
CX044 205 0884 083 4P CON.BASE(TUC-P)
CX047 205 0343 045 4P CONN.BASE(KR-PH)
CX063-069 205 0943 018 6P CON.BASE(TUC-P)
CX082 205 0884 096 8P CON BASE(TUC-P)
CX118 205 1091 024 11P CON BASE TWG-P
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
