Denon AVR-2803 Service Manual

66
66
AVR-2803/983/AVC-2870
CX134 205 1091 037 13P CON BASE TWG-P
JK501 205 1250 001 8P SP TERMINAL(V0)
JK502 205 1252 009 4P SP TERMINAL(V0)
JK503 205 1251 000 6P SP TERMINAL(V0)
JK504 204 8217 031 H/P JACK (BK(AU))
JK801,802 204 8540 009 4P PIN JACK
L101,102 235 0068 004 INDUCTOR(1MH)
L201 235 0068 004 INDUCTOR(1MH)
L301,302 235 0068 004 INDUCTOR(1MH)
L401,402 235 0068 004 INDUCTOR(1MH)
RL101 214 0217 007 RELAY(DS24D2)
RL201 214 0217 007 RELAY(DS24D2)
RL301,302 214 0217 007 RELAY(DS24D2)
RL401 214 0217 007 RELAY(DS24D2)
RL501 214 0223 004 RELAY(EC2-24N35)
S501 212 0420 005 1P PUSH SW(NON LOCK)
! T501 233 0644 008 MINI TRANS(383-N)
TP101 205 0190 065 6P NH CONNECTOR BASE
TP301 205 0190 081 8P NH CONNECTOR BASE
W301 203 0461 002 1P SIN CON.ASS'Y
W501 203 0459 014 1P SIN CON. ASS'Y
W502 203 0475 056 1P CONTACT ASS
W716 203 0440 010 1P CONTACT ASS'Y
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
