Denon AVR-2803 Service Manual

68
68
AVR-2803/983/AVC-2870
RESISTORS GROUP
R932 241 2387 908 RD14B2E010JNBST
R934 244 2055 996 RS14B3A122JNBST(S)
R939,940 244 2055 996 RS14B3A122JNBST(S)
CAPACITORS GROUP
C214,215 257 0511 904 CK73F1H103ZT
C251-254 257 0511 904 CK73F1H103ZT
C256 247 2018 903 RM73B--0R0KT
C259,260 254 4538 939 CE04W1C470MT SMG/RE3
C261,262 257 0511 904 CK73F1H103ZT
C263 254 4302 974 CE04W1A101MT(SRE)
C264 247 2018 903 RM73B--0R0KT
C265 254 4538 939 CE04W1C470MT SMG/RE3
C267 254 4538 939 CE04W1C470MT SMG/RE3
C268 247 2018 903 RM73B--0R0KT
C272 247 2018 903 RM73B--0R0KT
C275 247 2018 903 RM73B--0R0KT
C277,278 257 0511 904 CK73F1H103ZT
C280 254 4302 974 CE04W1A101MT(SRE)
C451,452 257 0516 954 CK73B1E104KT
C453,454 254 4538 939 CE04W1C470MT SMG/RE3
C455 254 4533 921 CE04W0J101MT SMG/RE3
C457 257 0504 940 CC73CH1H330JT
C458 257 0501 901 CK73B1H103KT (1608)
C459,460 257 0503 925 CC73CH1H100DT
C461 255 1265 978 CQ93M1H223JT(B)
C462 254 4524 972 CE04W1H4R7MT SMG/RE3
C463 257 0506 951 CC73CH1H101JT
C464 254 4524 943 CE04W1H010MT SMG/RE3
C465 254 4538 900 CE04W1C100MT SMG/RE3
C466 255 1264 908 CQ93M1H102JT(B)
C467 254 4536 928 CE04W1A101MT SMG/RE3
C468 257 0511 904 CK73F1H103ZT
C469 255 1264 911 CQ93M1H122JT(B)
C470 257 0506 993 CC73CH1H151JT
C471 254 4524 943 CE04W1H010MT SMG/RE3
C472 256 1058 955 CF93A1H683JT (JL)
C473 257 0508 917 CC73CH1H471JT
C474 257 0510 918 CK73B1H332KT
C486,487 257 0504 940 CC73CH1H330JT
C488 254 4536 928 CE04W1A101MT SMG/RE3
C489 257 0511 904 CK73F1H103ZT
C490 254 4538 900 CE04W1C100MT SMG/RE3
C503,504 254 4538 939 CE04W1C470MT SMG/RE3
C505-512 257 0511 904 CK73F1H103ZT
C513,514 254 4536 928 CE04W1A101MT SMG/RE3
C517,518 254 4538 939 CE04W1C470MT SMG/RE3
C521-524 257 0511 904 CK73F1H103ZT
C529,530 254 4536 928 CE04W1A101MT SMG/RE3
C532,533 256 1058 939 CF93A1H473JT (JL)
C534 254 4524 943 CE04W1H010MT SMG/RE3
C535 256 1058 939 CF93A1H473JT (JL)
C536 247 2018 903 RM73B--0R0KT
C539 247 2018 903 RM73B--0R0KT
C542 247 2018 903 RM73B--0R0KT
C546 247 2018 903 RM73B--0R0KT
C588 257 0512 903 CK73F1E104ZT
C601 257 0501 901 CK73B1H103KT (1608)
C602 254 4313 918 CE04W1H100MT(ASF)
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
