AVR-2803/983/AVC-2870
C603 257 0512 903 CK73F1E104ZT
C604 254 4533 947 CE04W0J331MT SMG/RE3
C605 257 0512 903 CK73F1E104ZT
C606 254 4533 947 CE04W0J331MT SMG/RE3
C607 257 0512 903 CK73F1E104ZT
C608 254 4533 947 CE04W0J331MT SMG/RE3
C704,705 257 0512 903 CK73F1E104ZT
C707 254 4402 926 CE04W1H0R1MT(KRE)
C711-714 254 4402 926 CE04W1H0R1MT(KRE)
C715 257 0512 903 CK73F1E104ZT
C716 254 4455 931 CE04W0J101MT(KRE)
C717 257 0512 903 CK73F1E104ZT
C901 253 1181 904 CK45F1H103ZT(DD-3)
C902 254 4573 952 CE04W1H2R2MT(RE3)
C903 253 1181 904 CK45F1H103ZT(DD-3)
C909 254 4524 943 CE04W1H010MT SMG/RE3
C911 254 4527 908 CE04W2A0R1MT SMG/RE3
C912 254 4524 985 CE04W1H100MT SMG/RE3
C913,914 254 4573 907 CE04W1H0R1MT(RE3)
C916-918 254 4573 907 CE04W1H0R1MT(RE3)
C919 254 4522 958 CE04W1V101MT SMG/RE3
C964,965 254 4573 907 CE04W1H0R1MT(RE3)
OTHER PARTS GROUP
CW031 203 4834 004 3P KR-DA CON CORD
CW077 205 0942 022 7P CON.SOCKET(TUC-P
CW078 205 1249 012 7P JE CON.BASE *
CW104 205 0885 053 10P CON.SOCKET TUC-P
CW116 205 1092 023 11P CON PLUG TWG-P
CW118 205 1092 023 11P CON PLUG TWG-P
CW133,134 205 1092 036 13P CON PLUG TWG-P
CW144,145 205 0885 011 14P CON.SOCKET TUC-P
CW154 205 1248 055 15P JE CON.PLUG
CW191-193 205 1092 007 19P CON.PLUG(TWG-P)
CW952 205 0885 040 15P CON.SOCKET TUC-P
CX073 205 1081 018 7P FJ CONN.BASE
CX115 205 0884 067 11P CON.BASE TUC-P
CX119 205 0884 067 11P CON.BASE TUC-P
CX132 205 0943 005 13P CON.BASE(TUC-P)
CX144,145 205 0884 012 14P CON.BASE TUC-P
CX152 205 0884 041 15P CON.BASE TUC-P
FB458,459 235 0049 900 BEADS INDUCTOR TAPE
FB701-703 235 0147 909 E.FIL(BLM21PG221SN1)
FB705-708 235 0147 909 E.FIL(BLM21PG221SN1)
FB709 247 0018 905 RM73B--0R0KT
JK201 204 8565 000 1P PIN JACK(S-GND
JK202-204 204 8516 017 3P PIN JACK
JK401-403 204 8415 011 3P S-TERMINAL
JK404 205 0902 004 1P S-TERMINAL(SW)
JK703 204 8649 007 MINI JACK (RD)
JK704 204 8657 002 MINI JACK
L451 235 0060 963 INDUCTOR(150)ST
S201 212 0373 000 ROT.ENCODER-EC16B
S202,203 212 5611 903 TACT SWITCH(TAPE H5)
S205 212 5611 903 TACT SWITCH(TAPE H5)
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
