Denon AVR-2803 Service Manual

76
76
AVR-2803/983/AVC-2870
C221 253 4465 902 CC45SL2H050CT
C225 255 1275 942 CQ93M2A221KT(B)
C307,308 254 4574 919 CE04W1H470MT(RE3)
C309,310 254 4573 981 CE04W1H100MT(RE3)
C311,312 255 1273 944 CQ93M1H221KT(B)
C315,316 255 1265 936 CQ93M1H103JT(B)
C317,318 254 4579 707 CE04W1H221MC(RE3)
C319,320 255 4242 943 CQ93P2A330JT(NH)
C321,322 253 4465 902 CC45SL2H050CT
C325,326 255 1275 942 CQ93M2A221KT(B)
C407,408 254 4574 919 CE04W1H470MT(RE3)
C409,410 254 4573 981 CE04W1H100MT(RE3)
C411,412 255 1273 944 CQ93M1H221KT(B)
C415,416 255 1265 936 CQ93M1H103JT(B)
C417,418 254 4579 707 CE04W1H221MC(RE3)
C419,420 255 4242 943 CQ93P2A330JT(NH)
C421,422 253 4465 902 CC45SL2H050CT
C425,426 255 1275 942 CQ93M2A221KT(B)
C525 253 8022 707 CK45F2EAC103MC
C599 254 4557 936 CE04W1H100MT(RFS)
C601-604 256 1058 971 CF93A1H104JT (JL)
C605,606 256 1042 903 CF93A2E104KT
C607 254 4541 939 CE04W1E470MT SMG/RE3
C608 254 4524 969 CE04W1H3R3MT SMG/RE3
C609 254 4524 943 CE04W1H010MT SMG/RE3
C610 254 6233 708 CE04W1C183MC(SMQ)
C611 256 1042 903 CF93A2E104KT
C613-616 254 4524 943 CE04W1H010MT SMG/RE3
C617 254 4403 734 CE04W1E472MC(SMG)
C618 254 4542 718 CE04W1E332MC SMG/RE3
C619,620 254 4524 943 CE04W1H010MT SMG/RE3
C622 254 4569 911 CE04W1E470MT(RE3)
C623 254 4382 910 CE04W1C221MT(ASF)
C625 254 4481 918 CE04W2A100MT(ASF)
C626,627 254 4313 798 CE04W1H221MC(ASF)
C628,629 254 4313 918 CE04W1H100MT(ASF)
C630,631 254 6235 706 CE68W1V682M *
C636 254 4538 939 CE04W1C470MT SMG/RE3
C643 254 4524 901 CE04W1H0R1MT SMG/RE3
OTHER PARTS GROUP
! AC501 203 3976 002 AC OUTLET(2P)
CW035,036 205 0697 034 JL CONNECTOR(F-E)
CW044 205 0885 082 4P CON.SOCKET(TUC-P)
CW063-069 205 0942 019 6P CON.SOCKET(TUC-P
CW082 205 0885 095 8P CON.SOCKET(TUC-P)
CW114 205 1229 016 11P FJ CONN.PLUG
CW115 205 0885 066 11P CON.SOCKET TUC-P
CW119 205 0885 066 11P CON.SOCKET TUC-P
CW132 205 0942 006 13P CON.SOCKET(TUC-P
CW143 205 1229 029 14P FJ CONN.PLUG
CW152 205 0885 040 15P CON.SOCKET TUC-P
CX022 205 0581 056 2P VH CONNECTOR BASE
CX024 205 0581 001 2P VH CONNECTOR BASE
CX062 205 0943 018 6P CON.BASE(TUC-P)
CX071,072 205 0943 021 7P CON.BASE(TUC-P)
CX078 205 1248 013 7P JE CON.PLUG *
CX085 205 0343 087 8P CONN.BASE(KR-PH)
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
