Denon AVR-2803 Service Manual

82
82
AVR-2803/983/AVC-2870
C528,529 257 0506 951 CC73CH1H101JT
C532 257 3011 919 CF73=1H102JT(ECHUB5)
C533 257 0512 903 CK73F1E104ZT
C534 257 3011 919 CF73=1H102JT(ECHUB5)
C536,537 254 4524 985 CE04W1H100MT SMG/RE3
C538 254 4347 748 CE04W1H010MC(ARSA)
C539 254 4524 985 CE04W1H100MT SMG/RE3
C540 257 0516 954 CK73B1E104KT
C541 257 0501 901 CK73B1H103KT (1608)
C542,543 257 3011 919 CF73=1H102JT(ECHUB5)
C544 257 0516 909 CK73B1E223KT
C545 257 0509 929 CK73B1H102KT
C546 257 0516 909 CK73B1E223KT
C549 254 4368 934 CE04W1E101MT(ASF)
C550 255 4235 057 CQ93P2A104J(NH)
C551 257 0512 903 CK73F1E104ZT
C552 257 0509 929 CK73B1H102KT
C553 255 4232 953 CQ93P2A472JT(NH)
C554 257 0512 903 CK73F1E104ZT
C555 254 4368 934 CE04W1E101MT(ASF)
C556 254 4367 906 CE04W1J470MT(ASF)
C560 257 0516 909 CK73B1E223KT
C564 254 4481 918 CE04W2A100MT(ASF)
C565 257 0506 935 CC73CH1H820JT
C570 257 0504 966 CC73CH1H390JT
C571 257 0508 962 CC73CH1H751JT
C573 257 0506 977 CC73CH1H121JT
C574,575 257 0506 993 CC73CH1H151JT
C578 257 0507 992 CC73CH1H391JT
C579 257 0508 962 CC73CH1H751JT
C580 257 0506 977 CC73CH1H121JT
C585,586 255 1273 902 CQ93M1H101KT(B)
C588 254 4367 906 CE04W1J470MT(ASF)
C596 257 0507 976 CC73CH1H331JT
C597,598 257 0506 993 CC73CH1H151JT
C599 257 0508 962 CC73CH1H751JT
C600 257 0508 917 CC73CH1H471JT
C601 257 0508 962 CC73CH1H751JT
C602 257 0506 993 CC73CH1H151JT
C603 257 0508 959 CC73CH1E681JT
C604 257 0506 935 CC73CH1H820JT
C605 257 0503 996 CC73CH1H200JT
C606 257 0506 935 CC73CH1H820JT
C607 257 0506 906 CC73CH1H620JT
C609 257 0506 935 CC73CH1H820JT
C610 257 0506 906 CC73CH1H620JT
C611 257 0506 935 CC73CH1H820JT
C620-624 254 4573 994 CE04W1H220MT(RE3)
C625,626 254 4583 995 CE04W1H220MT(ROB)
C627 254 4573 994 CE04W1H220MT(RE3)
C628-631 254 4573 907 CE04W1H0R1MT(RE3)
C632,633 254 4367 906 CE04W1J470MT(ASF)
C634,635 254 4481 918 CE04W2A100MT(ASF)
C638 257 0508 959 CC73CH1E681JT
C639 257 0508 962 CC73CH1H751JT
C640 257 0507 992 CC73CH1H391JT
C641 257 0507 976 CC73CH1H331JT
C642,643 257 0507 992 CC73CH1H391JT
C644 257 0507 947 CC73CH1H241JT
C645 257 0507 992 CC73CH1H391JT
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
