Denon AVR-2803 Service Manual

83
83
AVR-2803/983/AVC-2870
C646 257 0501 901 CK73B1H103KT (1608)
C801-804 257 0511 904 CK73F1H103ZT
C805 257 0501 901 CK73B1H103KT (1608)
C806 254 4368 934 CE04W1E101MT(ASF)
C808 254 4368 934 CE04W1E101MT(ASF)
C809 257 0512 903 CK73F1E104ZT
C811 257 0512 903 CK73F1E104ZT
C813,814 257 0503 983 CC73CH1H180JT
C815 257 0511 904 CK73F1H103ZT
C817 254 4368 934 CE04W1E101MT(ASF)
C818 254 4313 963 CE04W1H010MT(ASF)
C819 254 4347 748 CE04W1H010MC(ARSA)
C822 254 4368 934 CE04W1E101MT(ASF)
C823 255 1265 936 CQ93M1H103JT(B)
C990 254 4538 900 CE04W1C100MT SMG/RE3
OTHER PARTS GROUP
AS801 417 0649 009 HEAT SINK *
CW042 205 0885 082 4P CON.SOCKET(TUC-P)
CW048 205 0885 082 4P CON.SOCKET(TUC-P)
CW061 205 0942 019 6P CON.SOCKET(TUC-P
CW071,072 205 0942 022 7P CON.SOCKET(TUC-P
CW076 205 0942 022 7P CON.SOCKET(TUC-P
CW083 205 0885 095 8P CON.SOCKET(TUC-P)
CW091 205 0885 037 9P CON.SOCKET TUC-P
CW095 205 0885 037 9P CON.SOCKET TUC-P
CW102 205 0885 053 10P CON.SOCKET TUC-P
CW111-113 205 0885 066 11P CON.SOCKET TUC-P
CW151 205 0885 040 15P CON.SOCKET TUC-P
CW157 205 0885 040 15P CON.SOCKET TUC-P
CX114 205 1228 017 11P FJ CONN.BASE
CX143 205 1228 020 14P FJ CONN.BASE
CX201,202 205 1246 002 20P PIN HEADER(9142)
FB501 247 2018 903 RM73B--0R0KT
FB503 247 2018 903 RM73B--0R0KT
FB504,505 235 0130 903 CHIP EMIFIL(11A121)
FB506 247 2018 903 RM73B--0R0KT
FB511 235 0130 903 CHIP EMIFIL(11A121)
FB512,513 247 2018 903 RM73B--0R0KT
FB519 235 0049 900 BEADS INDUCTOR TAPE
FB521,522 235 0049 900 BEADS INDUCTOR TAPE
FB801 235 0130 903 CHIP EMIFIL(11A121)
FB803-808 235 0130 903 CHIP EMIFIL(11A121)
JK101-103 204 8513 010 6P PINJACK(S-GND)
JK301 204 8545 004 4P PIN JACK(GND)
JK302 204 8513 010 6P PINJACK(S-GND)
JK401,402 204 8545 004 4P PIN JACK(GND)
JK501 204 8658 001 2P PIN JACK(C-TYPE)
TP801 205 0343 074 7P CONN.BASE(KR-PH)
W703 203 0461 002 1P SIN CON.ASS'Y
X801 399 0624 001 X'TAL(15.0MHZ)
412 2404 069 PWB HOLDER (WLS-12)
473 7002 018 3X8 CBTS (S)-Z
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
