Denon AVR-2809CI


Getting Started Setup Playback Remote Control Multi-zone Information Troubleshooting Specifications
"4%/8
R
L
R
L
R
L
R
L
"6%*0
"6%*0
$0"9*"-
065
3-
065
(/%
"6%*0
065
R
L
Record Player
• When connecting a record player with an MC cartridge, use a
commercially available MC head amplifier or a step-up transformer.
• Induction humming (a booming sound) may be produced from the
speakers if the volume is raised with no record player connected.
• With some record players, noise may be generated when the ground
wire is connected. If so, disconnect the ground wire.
• When using a record player with a built-in phono equalizer, set the
phono equalizer to “OFF”.
Turntable (MM cartridge)
NOTE
The AVR-2809CI’s SIGNAL GND terminal is meant to reduce noise when
a record player is connected. This is not a safety ground terminal.
CD Player
CD player
When using an optical cable for the digital audio connection, make the
settings at menu “Input Setup” – “Assign” – “Digital In” (vpage
38).
iPod
®
iPod
• With the default settings, the iPod can be used connected to the
VCR (iPod) connector.
• To assign the iPod to a connector other than VCR (iPod), make the
settings at menu “Input Setup” – “(input source to which iPod dock
assigned)” – “Assign” – “iPod Dock” (vpage 39).
Use a DENON control dock for iPod (ASD-1R, ASD-11R, ASD-3N or
ASD-3W sold separately) to connect the iPod to the AVR-2809CI. For
instructions on the control dock for iPod settings, refer to the control
dock for iPod’s operating instructions.
Connections
