128
AVR-3310CI/AVR-3310/AVR990/AVC-3310
PARTS LIST OF P.W.B. UNIT
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
EU(AVR-3310) : U.S.A. model EC(AVR-3310) : Canada model
E2(AVR-3310) : Europe model E1C(AVC-3310) : Chaina model
990E3(AVR-990) : U.S.A. & Canada model
8U-110060 FRONT P.W.B. UNIT ASS'Y (for EU,EC,E2 model)
8U-110060B FRONT P.W.B. UNIT ASS'Y (for 990E3 model)
8U-110060C FRONT P.W.B. UNIT ASS'Y (for E1C model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D2623602003 GP1UE271XKVF
z IC102 00D2680073905 ICP-N15T
IC701 00D2690240003 GP1FMV31RK0F
IC702 00D2631289900 AZ4580MTR-E1
IC901 00D2621205907 TC74HCU04AF(TP1) +C
IC902 00D2623561908 TC74VHC14F
TR101 00D2690191903 KRA104S-RTK/P (47K-47K)
TR102 00D2730464901 KTC3875S-GR-RTK/P
TR103 00D2690193901 KRC104S-RTK/P (47K-47K)
TR106 00D2730494900 KTC2022D-Y-RTF/P
TR111-113 00D2730464901 KTC3875S-GR-RTK/P
TR114 00D2710312905 KTA1504S-GR-RTK/P
TR115 00D2690192902 KRC102S-RTK/P (10K-10K)
TR116 00D2710312905 KTA1504S-GR-RTK/P
TR117 00D2690192902 KRC102S-RTK/P (10K-10K)
TR301 00D2690192902 KRC102S-RTK/P (10K-10K)
TR302,303 00D2710312905 KTA1504S-GR-RTK/P
TR304 00D2690193901 KRC104S-RTK/P (47K-47K)
D101 00D2760704916 1SR35-400A(T82)
D103 00D2760794900 KDS160-RTK/P
D105 00D2760794900 KDS160-RTK/P
D107 00D2760794900 KDS160-RTK/P
D108 00D2760704916 1SR35-400A(T82)
D901 00D2760738908 KDS226-RTK/P (A-K)
D902 00D2760738908 KDS226-RTK/P (A-K)
D903 00D2760738908 KDS226-RTK/P (A-K)
ZD101 00D2760761975 MTZJ18B T77
ZD102 00D2760762903 MTZJ24B T77
ZD103 00D2760636903 MTZJ8.2BT77
ZD701-703 00D2760683930 UDZS5.1B-TE17 +C
LD101 263010032409S SIR-341STA49
LD102 176010001402S SELT5E20C-S(TP15)
LD103 00D9630366108 LED BL-BEG204-L 5PI
K500052004010S
LD301 00D9630366108 LED BL-BEG204-L 5PI
K500052004010S
FL101 172010006108D FLD(19-ST-02GINK)
