AVR-3310CI/AVR-3310/AVR990/AVC-3310
(2) Disconnect the connector wires, then remove the screws.
6. SPEAKER UNIT
(1) Disconnect the VH connector and conector.
7. AMP CONNECT UNIT
(1) Disconnect the connector.
PTC UNIT
ً
ً
ً
Direction of photograph: A
s
Proceeding : TOP COVER →
→
→
→→
BACK PANEL UNIT ASSY
A.VIDEO UNIT, A.AUDIO UNIT and RADIATOR UNIT ASSY
DIGITAL UNIT ASSY
REG UNIT SPEAKER UNIT
d
CX851CX891
CX876
CX874
CX871
CX873
CX872
CX875
CX877
View from bottom
Proceeding : TOP COVER →
→
→
→→ →
BACK PANEL UNIT ASSY
A.VIDEO UNIT, A.AUDIO UNIT and RADIATOR UNIT ASSY
DIGITAL UNIT ASSY
REG UNIT SPEAKER UNIT AMP CONNECT UNIT
d
CX803CX805
CX806CX811CX812CX807
CX804
Direction of photograph: A
