AVR-3310CI/AVR-3310/AVR990/AVC-3310
8. P.AMP UNIT
(1) Remove the screws.
Proceeding : TOP COVER →
→
→
→
→
→→
→
BACK PANEL UNIT ASSY
A.VIDEO UNIT, A.AUDIO UNIT and RADIATOR UNIT ASSY
DIGITAL UNIT ASSY
REG UNIT
P.AMP UNIT
SPEAKER UNIT AMP CONNECT UNIT
