AVR-3310CI/AVR-3310/AVR990/AVC-3310
8U-210082 MAIN CPU P.W.B. UNIT ASS'Y (for EU,EC model)
8U-210082A MAIN CPU P.W.B. UNIT ASS'Y (for E2 model)
8U-210082B MAIN CPU P.W.B. UNIT ASS'Y (for 990E3 model)
8U-210082C MAIN CPU P.W.B. UNIT ASS'Y (for E1C model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 236810072506S ICL3232CVZ-T
IC102 00D2623360905 LC72722PM-TLM E2
IC103 231310009508S PQ033DNA1ZPH
IC104 00D2631286903 PQ120DNA1ZPH E2
IC105,106 00D2631286903 PQ120DNA1ZPH
IC108 234810015507S BU4248F-TR
IC109 00D2631289900 AZ4580MTR-E1
IC110 00D2631289900 AZ4580MTR-E1 E2, E1C
IC111 00D2630706905 NJM2903M-TE1 +C
IC112 00MHC007805K0 TC74VHCT125AFT OUAD BUS BUFFER
IC113 231810017528S TK73333WTL-G
IC114 00MHC007805K0 TC74VHCT125AFT OUAD BUS BUFFER
IC507,508 00D2623437906 TC74VHCT244AFT
IC701 8R2431004300D MAIN CPU SUB ASSY
(R5F64169DFD)
IC702 246810026500S R1EX24256ASAS0A
TR101 00D2690191903 KRA104S-RTK/P (47K-47K)
TR102,103 00D2730464901 KTC3875S-GR-RTK/P
TR104 00D2690191903 KRA104S-RTK/P (47K-47K)
TR105,106 00D2690066902 DTC323TKT96 E2
TR107 00D2690192902 KRC102S-RTK/P (10K-10K) E2
TR108 00D2690086908 DTA114TKT96 E2
TR110 00D2690192902 KRC102S-RTK/P (10K-10K) E2
TR111 00D2710326904 2SA1954(B)-TE85L
TR112 00D2690192902 KRC102S-RTK/P (10K-10K)
TR116,117 00D2730464901 KTC3875S-GR-RTK/P
TR124 00D2710326904 2SA1954(B)-TE85L
TR125,126 00D2690192902 KRC102S-RTK/P (10K-10K)
TR127 00D2710326904 2SA1954(B)-TE85L
TR128 00D2690192902 KRC102S-RTK/P (10K-10K)
TR129 00D2710326904 2SA1954(B)-TE85L
TR130 00D2690191903 KRA104S-RTK/P (47K-47K)
TR131 00D2730464901 KTC3875S-GR-RTK/P
TR132 00D2690192902 KRC102S-RTK/P (10K-10K)
TR133 00D2690193901 KRC104S-RTK/P (47K-47K)
TR134,135 00D2730464901 KTC3875S-GR-RTK/P
TR136 00D2690192902 KRC102S-RTK/P (10K-10K)
TR139,140 00D2690192902 KRC102S-RTK/P (10K-10K)
TR141 00D2690191903 KRA104S-RTK/P (47K-47K)
TR704 00D2690193901 KRC104S-RTK/P (47K-47K)
TR705-707 00D2690192902 KRC102S-RTK/P (10K-10K)
TR712 00D2690184907 KRA102S-RTK/P (10K-10K)
TR713 00D2690192902 KRC102S-RTK/P (10K-10K)
D106 00D2760794900 KDS160-RTK/P
D108,109 00D2760684900 RB051L-40TE25 +C
D113 nsp RM73B--0R0KT +2125
s
s
s
s
s
s
s
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.
