28
AVR-3310CI/AVR-3310/AVR990/AVC-3310
Adjustment volume is set for 8U-110062-1 〜 7. The test point is at 8U-110063-3.
Insert an adjustment driver / connection terminal from an adjustment aperture of 8U-110061-4(POWER SUPPLY Unit)P.W.B..
SL ch
FR ch
FL ch
SR ch
CX660
C ch
SBR ch
SBL ch
CX680
Audio Section
DC Voltmeter
VR601 VR101
VR501
VR301
VR401 VR201
VR701
8U-110061-4 POWER SUPPLY Unit
8U-310039 DIGITAL Unit
