82
AVR-3310CI/AVR-3310/AVR990/AVC-3310
R5F64169DFD Terminal
Pin Pin Name Synbol I/O Type Pullup LvCnv STBY stop Function
1
P96/TXD4 NC O C - - O/L O/L
2
P95/(CLK4) NC O C - - O/L O/L
3
P94/(CTS4) TU STB O C - 3/5 O/L O/L PLL control pin(LC72131 & LC72720)
4
P93/(CTS3) D.OSD MIFO_BUSY I - - - O/L O/L D.OSD CPU control pin
5
P92/TXD3 HDRADIO MOHI O C - - O/L O/L HD RADIO control
6
P91/RXD3 HDRADIO MIHO I - - - O/L O/L HD RADIO control
7
P90/(CLK3) E POWER O C - - O/L O/L ETHER POWER control pin
8
P146/INT8 POWER KEY I - M3VPu - I I POWER KEY(WAIT MODE cancel interrupt port)
9
P145/INT7 (B.DOWN2) I - M3VPu - I I Not used(Power down detect (Power down : L))
10
P144/INT6 PROTECTION
(ASO/DC)
I - (3Vin) - I I PROTECTION detect pin(ASO/DC)
11
P143 CPU POWER O C - - O/L O/L MAIN CPU POWER control pin (POWER ON: H)(ETHER=ON or CEC
ON:STANDBY: H )
12
VDC0 VDC0 - - - - - - Smoothing capacitor connection pin
13
P141(INPUT
ONLY)
REQ SOMI I - - - I O/L
MAIN-SUB
μ
com communication control output pin
14
VDC1 VDC1 - - - - - - Smoothing capacitor connection pin
15
NSD NSD - - M3VPu - - - Emulator communication pin
16
CNVss CNVSS - - Pd - - - Single-chip / Micro-processor mode switching (Normal single-chip: L,
Rewrite boot program star: H input set)
17
P87/(XCIN) E RESET O C Pd - O/L O/L ETHERNET RESET control pin
18
P86/(XCOUT) 232C POWER/REMOTE
PWR
O C - - O/L O/L 232C POWER control pin(ON: H)/REMOTE POWER
19
RESET RESET - - M3VPu - - - Reset input (reset: L)
20
XOUT X2 - - - - - - Clock output
21
VSS VSS - - - - - - GND
22
XIN X1 - - - - - - Clock input
23
VCC VCC1 - - - - - - +3V
24
P85/NMI NMI I - M3V - I I Not used(Fixed to H)
25
P84/INT2 REMOTE DET I - (3Vin) - I I ROOM TO ROOM signal detect pin(detected: H)
26
P83/INT1 B.DOWN I - (3Vin) - I I Power down detect (Power down : L)
27
P82/INT0 REMOCON I - 3VIn/Pd - I I Remote control signal input
28
P81 FL CE1 O C - (3/5) O/L O/L FL display unit control pin
29
P80/RXD5 iPod RXD MIIO I N (5VIn) - O/L O/L IPOD communication control pin
30
P77/CLK5 TU/RDS CLK 0 C SW5VPu 3/5 O/L O/L PLL & RDS control pin (LC72131 & LC72720)
31
P76/TXD5 iPod TXD MOII O C (5VIn) 3/5 O/L O/L IPOD communication control pin
32
P75/RXD8 (SIRIUS MI)/RDS DOUT I N 5VIn - O/L O/L SIRIUS control pin/RDS data inputpin(LC72720)
33
P74/CLK8 EXP DATA O C - (3/5) O/L O/L Extended EXP control pin
34
P73/TXD8 (SIRIUS MO)/RDS CE O C SW5VPu 3/5 O/L O/L SIRIUS control pin/RDS control pin(LC72720)
35
P72/CLK2 D.OSD CPU CLK O C - - O/L O/L D.OSD CPU control pin
36
P71/RXD2/
(MSCL)
D.OSD CPU RX I - - - O/L O/L D.OSD CPU control pin
37
P70/TXD2/
(MSDA)
D.OSD CPU TX O C - - O/L O/L D.OSD CPU control pin
38
P67/TXD1 TXD MO232I O C - (3/5) O/L O/L Data transfer pin to outside (AMX)/MITSUBISHI writer rewrite
39
VCC VCC1 - - - - - - +3V
40
P66/RXD1 RXD MI232O I - - - I O/L Date receive pin from outside(AMX)/MITSUBISHI writer rewrite
41
VSS VSS - - - - - - GND
42
P65/CLK1/
SCLK(L)
EXP CLK O C - - O/L O/L Extended EXP control pin
43
P64/BUSY TU DOUT I N (5VIn) - O/L O/L TUNER PLLdata inputpin (LC72131)
44
P63/TXD0 E_TXDMOEI O C - - O/L O/L ETHERNET comm. control pin
45
P62/RXD0 E_RXDMIEO I - - - I O/L ETHERNET comm. control pin
46
P61/CLK0 FL CLK O C - - O/L O/L FL display unit control pin
47
P60/CTS0 FL DATA O C - - O/L O/L FL display unit control pin
48
P137 ACK SIMO O C - - O/L O/L
MAIN-SUB
μ
com comm. control output pin
49
P136/ISCLK2 CLKMO O C - - O/L O/L
MAIN-SUB
μ
com comm. control output pin
50
P135/ISRXD2 SOMI I - - - I O/L
MAIN-SUB
μ
com comm. control output pin
51
P134/ISTXD2 MOSI O C - - O/L O/L
MAIN-SUB
μ
com comm. control output pin
52
P57/(RDY) NC O C M3VPu - I I
53
P56/(ALE) NC O C - - O/L O/L
54
P55/(HOLD)/
EPM
FRASH EPM I C M3VPu - I I Rewrite boot program start : L input set
55
P54/(HLDA) NC O C - - O/L O/L
56
P133 MUTE POWER O C - - O/L O/L MUTE +B control pin
57
VSS VSS - - - - - - GND
58
P132 D.OSD MOFI_BUSY O C - O/L O/L D.OSD CPU control pin
