Video
Setting items Setting details
i/p Scaler
Convert the input source
resolution to the resolution
set.
CBL/SAT
DVD
Blu-ray
z
GAME
z
AUX1
AUX2
z
MEDIA PLAYER
CD
z
NETWORK
TV AUDIO
z
Analog : Use i/p scaler function for analog video signal.
Analog & HDMI : Use i/p scaler function for analog and HDMI video signal.
HDMI : Use i/p scaler function for HDMI video signal.
Off : Do not use i/p scaler function.
•“Analog & HDMI” can be set for input sources for which an HDMI input
connector is assigned.
•Which items can be set depend on the input source assigned to each
input connector.
•This function is not effective when the input signal is “x.v.Color”, 3D,
sYCC 601 color, Adobe RGB color, Adobe YCC 601 color or computer
resolution.
Resolution
Set the output resolution.
You can set “Resolution”
separately for HDMI output
of the analog video input
and HDMI input.
CBL/SAT
DVD
Blu-ray
z
GAME
z
AUX1
AUX2
z
MEDIA PLAYER
CD
z
NETWORK
TV AUDIO
z
Auto : The number of pixels the TV connected to the HDMI MONITOR
OUT connector supports is detected automatically and the appropriate
output resolution is set.
480p/576p / 1080i / 720p / 1080p / 1080p:24Hz / 4K : Set the output
resolution.
•This item can be set when “i/p Scaler” is set to anything other than
“Off”.
•When “i/p Scaler” is set to “Analog & HDMI”, the resolution of both the
analog video input signal and HDMI input signal can be set.
•To watch 1080p/24Hz pictures, use a TV that supports 1080p/24Hz video
signals.
•When set to “1080p:24Hz”, you can enjoy film-like pictures for film
sources (in 24 Hz). For video sources and mixed sources, we recommend
setting the resolution to “1080p”.
•It is not possible to convert a 50 Hz signal into 1080p/24Hz. It is output
at a resolution of 1080p/50Hz.
Setting items Setting details
Progressive Mode
Set an appropriate
progressive conversion
mode for the source video
signal.
CBL/SAT
DVD
Blu-ray
z
GAME
z
AUX1
AUX2
z
MEDIA PLAYER
CD
z
TV AUDIO
z
Auto : The video signal is automatically detected and the appropriate
mode is set.
Video : Select mode suitable for video playback.
Video and Film : Select mode suitable for video and 30-frame film
material playback.
This item can be set when “i/p Scaler” is set to anything other than
“Off”.
Aspect Ratio
Set the aspect ratio for the
video signals output to the
HDMI.
CBL/SAT
DVD
Blu-ray
z
GAME
z
AUX1
AUX2
z
MEDIA PLAYER
CD
z
NETWORK
TV AUDIO
z
16:9 : Output at 16:9 aspect ratio.
4:3 : Output at 4:3 aspect ratio.
“Aspect Ratio” can be set when “i/p Scaler” is set to anything other
than “Off”.
z “Blu-ray”, “GAME”, “AUX2”, “TV AUDIO” or “CD” can be set when “HDMI” or “COMP”
(vpage126) has been assigned.
Component Video Out
Default settings are underlined.
Sets the zone to which the component video output connector is assigned.
Setting items Setting details
Component
MAIN ZONE : Assigns the component video output connector to MAIN
ZONE.
ZONE2 : Assigns the component video output connector to ZONE2.
To Next Page
