41
9
OPERATION
Before operating
1
Refer to “CONNECTIONS” (pages 6 to 13) and check that all
connections are correct.
2
Select “AMP” using the RECEIVER button.
(only when operating with the remote control unit)
3
Turn on the power.
Press the POWER switch (button).
RECEIVER
ON / STANDBY
(Main unit) (Remote control unit)
Light
OFF
TV
CD
CDR/MD/ TAPE RECEIVER
VCR DBS/CABLE VDP DVD
POWER
REMOTE CONTROL UNIT
RC-883
ON /
SOURCE
DISPLAY
MENU
2
3
When pressed, the power turns on and the display lights. The sound
is muted for several seconds, after which the unit operates normally.
When pressed again, the power turns off, the standby mode is set
and the display turns off.
Whenever the ON/STANDBY button is in the STANDBY state, the
apparatus is still connected on AC line voltage. Please be sure to
unplug the cord when you leave home for, say, a vacation.
(Remote control unit)

Other manuals for Denon AVR-3801

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-3801 and is the answer not in the manual?

Denon AVR-3801 Specifications

General IconGeneral
Channels7.1
Power Output105 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion0.05%
TypeAV Receiver
Input Sensitivity200 mV (Line)
Input Impedance47 kOhms (Line)
Output Voltage1.2 V (Pre Out)
Video SwitchingComposite, S-Video
Speaker Impedance6 - 16 Ohms
Tuning rangeFM, AM
Digital inputs/outputsoptical, coaxial
Signal-to-Noise Ratio100 dB (Line)
Output Impedance1.2k ohms
