Denon AVR-3801 Operating Instructions

44
After starting playback
[1] Adjusting the sound quality (TONE)
The tone control function will not work in the direct mode.
1
The tone switches as follows each time the TONE CONTROL
button is pressed.
TONE
CONTROL
(Main unit)
2
With the name of the volume to be
adjusted selected, turn the SELECT
knob to adjust the level.
SELECT
NOTE:
To prevent hearing loss, do not raise the volume level excessively
when using headphones.
[3] Turning the sound off temporarily (MUTING)
1
Use this to turn off the audio output
temporarily.
Press the MUTING button.
Cancelling MUTING mode.
Press the MUTING button again.
MUTING
1
2
3
SKIP
SKIP
ENTER
+
-
+
-
TUNER
PHONO
CD
SHIFT
MUTING
TUNING
1
• To increase the bass or treble: Turn the control clockwise.
(The bass or treble sound can be increased to up to +12 dB
in steps of 2 dB.)
• To decrease the bass or treble: Turn the control clockwise.
(The bass or treble sound can be decreased to up to –12 dB
in steps of 2 dB.)
[2] Listening over headphones
1
Connect the headphones to the
PHONES jack of the front panel.
1
PHONES
2
OUTPUT
• The output to the speaker and pre-out jacks is turned off
and no sound is produced from the speakers.
Caution: Switching off the power of the unit and the unit will
cancel the settings.
(Main unit)
(Remote control unit)
Press the OUTPUT button to play the sound over the
headphones only.
+10
0
TV/
VCR
SURROUND
OUTPUT
TEST
TONE
SPEAKER
5CH / 7CH
STEREO
DOLBY/DTS
SURROUND
DSP
SIMU.
2
BASS TREBLE

Denon AVR-3801 Specifications

General

Channels	7.1
Power Output	105 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Type	AV Receiver
Input Sensitivity	200 mV (Line)
Input Impedance	47 kOhms (Line)
Output Voltage	1.2 V (Pre Out)
Video Switching	Composite, S-Video
Speaker Impedance	6 - 16 Ohms
Tuning range	FM, AM
Digital inputs/outputs	optical, coaxial
Signal-to-Noise Ratio	100 dB (Line)
Output Impedance	1.2k ohms
