Denon AVR-3803 Service Manual

70
AVR-3803/1083/AVC-3570
Ref. No. Part No. Part Name Remarks New Ref. No. Part No. Part Name Remarks New
1U-3471D CONTROL UNIT ASS’Y (For Japan model)
CAPACITORS GROUP
C102 257 0512 903 CK73F1E104ZT
C103,104 254 4193 905 CE04W1C100MT (SRA)
C107 256 1058 971 CF93A1H104JT (JL)
C109 254 4196 999 CE04W1H220MT (SRA)
C110-113 257 0511 904 CK73F1H103ZT
C115 257 0511 904 CK73F1H103ZT
C117 257 0509 929 CK73B1H102KT
C120 257 0504 937 CC73CH1H300JT
C121 254 4193 905 CE04W1C100MT (SRA)
C122 257 0511 917 CK73F1H223ZT
C123,124 254 4524 943 CE04W1H010MT SMG/RE3
C125 257 0511 904 CK73F1H103ZT
C126 257 0509 929 CK73B1H102KT
C128 254 4540 011 CE04W1J471M(SMG) ∗
C129 256 1042 903 CF93A2E104KT
C531 257 0511 904 CK73F1H103ZT
C537 254 4536 957 CE04W1A471MT SMG/RE3
C539,540 254 4533 921 CE04W0J101MT SMG/RE3
C545 257 0509 929 CK73B1H102KT
C546 254 4533 934 CE04W0J221MT SMG/RE3
C547,548 257 0503 967 CC73CH1H150JT
C549 257 0509 929 CK73B1H102KT
C550 257 0516 954 CK73B1E104KT
C551,552 257 0509 929 CK73B1H102KT
C553 257 0516 954 CK73B1E104KT
C554 254 4534 713 CE04W0J332MC SMG/RE3
C555 257 0511 904 CK73F1H103ZT
C557 257 0509 929 CK73B1H102KT
C558 257 0516 954 CK73B1E104KT
C559,560 257 0509 929 CK73B1H102KT
C561,562 257 0516 954 CK73B1E104KT
C564 257 0512 903 CK73F1E104ZT
C565,566 257 0516 954 CK73B1E104KT
C567 254 4533 921 CE04W0J101MT SMG/RE3
C568,569 257 0509 929 CK73B1H102KT
C570 254 4368 934 CE04W1E101MT(ASF)
C571 257 0512 903 CK73F1E104ZT
C574 257 0511 904 CK73F1H103ZT
C575 254 4522 903 CE04W1V4R7MT SMG/RE3
C576 257 0512 903 CK73F1E104ZT
C581 256 1058 984 CF93A1H124JT (JL)
C806 257 0516 909 CK73B1E223KT
SEMICONDUCTORS GROUP
IC101 262 2549 002 LC75721E
IC102 499 0303 004 GP1UM271XK
IC103 262 2745 903 BU2090F(E2)
IC104 268 0073 905 ICP-N15T
IC503 263 1040 903 BU4094BCF-E2
IC505 263 1048 002 BA033T
IC506 262 3150 005 M30624MGA ∗
IC507 262 2517 908 SN74LV08APW-EL2
TR101 271 0301 903 2SA/KTA1268BL-AT
TR111 269 0184 907 KRA102S-RTK
TR112 269 0191 903 KRA104S-RTK(47K-47K)
TR113-115 269 0193 901 KRC104S-RTK(47K-47K)
TR116,117 269 0191 903 KRA104S-RTK(47K-47K)
TR118 269 0192 902 KRC102S-RTK(10K-10K)
TR509 272 0161 900 2SB1412TL(PQR)
TR510 269 0192 902 KRC102S-RTK(10K-10K)
TR513 272 0161 900 2SB1412TL(PQR)
TR514-516 269 0192 902 KRC102S-RTK(10K-10K)
TR517 272 0161 900 2SB1412TL(PQR)
TR518 269 0192 902 KRC102S-RTK(10K-10K)
TR519 269 0193 901 KRC104S-RTK(47K-47K)
TR520 269 0191 903 KRA104S-RTK(47K-47K)
TR521-523 269 0193 901 KRC104S-RTK(47K-47K)
TR524 273 0464 901 KTC3875SGR-RTK
D103 276 0704 903 1SR35-400A(T93X)
D104 276 0468 906 HZS9B-1TD
D109-111 276 0432 903 1SS270A TE (TAPE)
D501,502 276 0704 903 1SR35-400A(T93X)
D503 276 0432 903 1SS270A TE (TAPE)
D504 276 0454 910 HZS3C-2TD
D505 276 0432 903 1SS270A TE (TAPE)
ZD101 276 0484 919 HZS33-2TD
LD102-107 393 9434 906 SEL1210S(TP2) Red
LD108 393 9452 904 SEL1410E(TP2) Green
LD109,110 393 9434 906 SEL1210S(TP2) Red
LD111-114 393 9452 904 SEL1410E(TP2) Green
RESISTORS GROUP
R137 241 2387 908 RD14B2E010JNBST
R579 241 2387 908 RD14B2E010JNBST
