Denon AVR-3803 Service Manual

74
AVR-3803/1083/AVC-3570
1U-3473D AUDIO/DIGITAL UNIT ASS’Y (For Japan model)
Ref. No. Part No. Part Name Remarks New Ref. No. Part No. Part Name Remarks New
SEMICONDUCTORS GROUP
IC101,102 262 2545 006 TC9274N-011
IC205 263 0896 909 NJM2068MD-TE1
IC207 263 0896 909 NJM2068MD-TE1
IC301 262 2919 001 TC9274N-017
IC302 263 0896 909 NJM2068MD-TE1
IC361 263 0896 909 NJM2068MD-TE1
IC371 262 3168 903 TC94A32F ∗
IC372 263 0898 907 NJM5532MD-TE1
IC373 262 3168 903 TC94A32F
∗
IC374 263 0898 907 NJM5532MD-TE1
IC376 262 3168 903 TC94A32F
∗
IC377 263 0898 907 NJM5532MD-TE1
IC378 262 3168 903 TC94A32F ∗
IC379 263 0898 907 NJM5532MD-TE1
IC501-505 262 3065 006 TORX141
IC506,507 262 3064 007 TOTX141
IC508 263 0934 900 BA4510F-E2
IC510-512 262 3077 900 TC74VHCU04FT
IC513,514 262 2944 908 SN74HC151APW-EL2
IC515 263 0934 900 BA4510F-E2
IC517 263 0934 900 BA4510F-E2
IC519 262 3069 905 PCM1804
IC520 262 3066 102 LC89057W-VF4-E(AC)
IC521 262 3062 902 FCX0-03(24.576MHZ)
IC522 262 2959 906 SN74LV244APW
IC523-526 262 3152 906 PCM1791 ∗
IC527 263 1098 900 LM833
IC529 263 1098 900 LM833
IC531 263 0896 909 NJM2068MD-TE1
IC533 263 0896 909 NJM2068MD-TE1
IC535 263 0898 907 NJM5532MD-TE1
IC536 263 1079 903 BA033FP
IC801,802 262 3175 909 74VHC00MTCX ∗
IC803 262 3176 908 74VHC74MTCX ∗
IC804 262 2870 904 74LVX157MTC
IC805 263 1164 009 PQ018EF01SZ
IC806 262 3167 001 TMP91CW12AF ∗
IC807 262 2517 908 SN74LV08APW-EL2
TR501 269 0192 902 KRC102S-RTK(10K-10K)
TR502 269 0184 907 KRA102S-RTK
TR503 269 0192 902 KRC102S-RTK(10K-10K)
TR504 269 0184 907 KRA102S-RTK
TR505-512 269 0192 902 KRC102S-RTK(10K-10K)
TR513-516 269 0184 907 KRA102S-RTK
TR517,518 273 0460 905 KTC2875B-RTK
TR519 269 0192 902 KRC102S-RTK(10K-10K)
TR520 269 0184 907 KRA102S-RTK
TR521-536 273 0460 905 KTC2875B-RTK
TR801 272 0161 900 2SB1412TL(PQR)
TR802 269 0192 902 KRC102S-RTK(10K-10K)
TR803 269 0184 907 KRA102S-RTK
TR804,805 269 0192 902 KRC102S-RTK(10K-10K)
D502,503 276 0738 908 KDS226-RTK(A-K)
D504-507 276 0740 909 KDS184-RTK(K-COM)
CAPACITORS GROUP
C105 247 2018 903 RM73B--0R0KT
C107-109 247 2018 903 RM73B--0R0KT
C110 257 0509 929 CK73B1H102KT
C117-120 254 4313 963 CE04W1H010MT(ASF)
C167,168 257 0507 976 CC73CH1H331JT
C174 247 2018 903 RM73B--0R0KT
C178 247 2018 903 RM73B--0R0KT
C188 257 0509 929 CK73B1H102KT
C205,206 254 4573 981 CE04W1H100MT(RE3)
C209,210 254 4573 949 CE04W1H010MT(RE3)
C211,212 254 4573 994 CE04W1H220MT(RE3)
C213,214 254 4573 981 CE04W1H100MT(RE3)
C217,218 254 4573 949 CE04W1H010MT(RE3)
C219,220 254 4573 994 CE04W1H220MT(RE3)
C319,320 257 0507 934 CC73CH1H221JT
C321,322 254 4538 900 CE04W1C100MT SMG/RE3
C323 257 0506 951 CC73CH1H101JT
C324,325 254 4533 934 CE04W0J221MT SMG/RE3
C326 257 0506 951 CC73CH1H101JT
C327,328 255 4199 999 CQ92M1H243JT(MRZ)
C329,330 255 1265 907 CQ93M1H682JT(B)
C331,332 254 4538 900 CE04W1C100MT SMG/RE3
C336 257 0509 929 CK73B1H102KT
C342 254 4573 949 CE04W1H010MT(RE3)
C344 254 4573 949 CE04W1H010MT(RE3)
C346 254 4573 949 CE04W1H010MT(RE3)
C348 254 4573 949 CE04W1H010MT(RE3)
C351 254 4573 949 CE04W1H010MT(RE3)
C353 254 4573 949 CE04W1H010MT(RE3)
C361,362 254 4538 900 CE04W1C100MT SMG/RE3
C363,364 254 4573 949 CE04W1H010MT(RE3)
C367-370 256 1058 955 CF93A1H683JT (JL)
C371,372 254 4573 994 CE04W1H220MT(RE3)
C374,375 254 4573 994 CE04W1H220MT(RE3)
C381-388 254 4573 965 CE04W1H3R3MT(RE3)
C389-392 257 0502 971 CC73CH1H5R0CT
C393-396 254 4313 963 CE04W1H010MT(ASF)
C397,398 254 4573 994 CE04W1H220MT(RE3)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-3803 Specifications

General

Channels	7.1
Dolby Digital	Yes
DTS	Yes
Component Video Inputs	3
S-Video Inputs	7
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
Analog Audio Inputs	9
Type	AV Receiver
THD	0.05%
Input Sensitivity	200 mV
Signal to Noise Ratio	100 dB
Frequency Response	10 Hz - 100 kHz
Digital Inputs	5 (3 Optical, 2 Coaxial)
Weight	33.1 lbs
Amplifier Channels	7
Signal-to-Noise Ratio	100 dB
Surround Sound Modes	Dolby Digital, DTS, Dolby Pro Logic II
Power Output	110W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Video Inputs	S-Video, Component
Input Sensitivity/Impedance	200 mV / 47 kOhm
Video Inputs/Outputs	S-Video, Component
Dimensions (W x H x D)	17.1 x 6.6 x 16.9 inches
