77
AVR-3803/1083/AVC-3570
Ref. No. Part No. Part Name Remarks
New
Ref. No. Part No. Part Name Remarks
New
1U-3475D VIDEO UNIT ASS’Y
(For Japan Model)
SEMICONDUCTORS GROUP
IC101 262 2013 907 BU4053BCF-E2
IC102-104 263 1082 903 TK15420MTL
IC105 262 2012 908 BU4052BCF-E2
IC108 262 2012 908 BU4052BCF-E2
IC109 262 3110 906 TC90A69F
IC110 263 1165 901 NJM2274R
IC111 262 3108 002 TA1270BF
IC112,113 263 1082 903 TK15420MTL
IC115 263 1082 903 TK15420MTL
IC117 263 1082 903 TK15420MTL
IC120 263 1040 903 BU4094BCF-E2
TR101,102 271 0312 905 2SA/KTA1504SGR-RTK
∗
TR700-703 273 0464 901 KTC3875SGR-RTK
TR705 271 0310 907 2SA1163(BL)
TR706 269 0144 905 DTC114YK-T146
TR707 269 0192 902 KRC102S-RTK(10K-10K)
D101 276 0773 905 RB501V-40
D701-705 276 0740 909 KDS184-RTK(K-COM)
RESISTORS GROUP
VR101-103 211 6146 940 V06PB102T(RH063)
∗
CAPACITORS GROUP
C101,102 257 0501 901 CK73B1H103KT (1608)
C103,104 254 4300 963 CE04W0J101MT(SRE)
C105,106 257 0503 941 CC73CH1H120JT
C107,108 257 0504 908 CC73CH1H220JT
C109,110 254 4300 918 CE04W0J100MT(SRE)
C111,112 257 0501 901 CK73B1H103KT (1608)
C113 254 4299 919 CE04W1C220MT(SRE)
C114,115 257 0501 901 CK73B1H103KT (1608)
C116 257 0516 954 CK73B1E104KT
C117,118 257 0501 901 CK73B1H103KT (1608)
C119 257 0508 959 CC73CH1E681JT
C120 257 3006 911 CF73=1C104JT(ECHUB5)
C121 254 4302 974 CE04W1A101MT(SRE)
C122-128 257 0501 901 CK73B1H103KT (1608)
C129 254 4300 963 CE04W0J101MT(SRE)
C130 257 0503 941 CC73CH1H120JT
C131 254 4299 919 CE04W1C220MT(SRE)
C132,133 257 0501 901 CK73B1H103KT (1608)
C134 257 0503 941 CC73CH1H120JT
C135,136 254 4299 919 CE04W1C220MT(SRE)
C137 254 4305 942 CE04W1HR47MT(SRE)
C138 254 4305 926 CE04W1HR22MT(SRE)
C139 257 3011 948 CF73=1H222JT(ECHUB5)
C140 254 4300 963 CE04W0J101MT(SRE)
C141 257 0501 901 CK73B1H103KT (1608)
C142 254 4305 984 CE04W1H2R2MT(SRE)
C143,144 257 0516 954 CK73B1E104KT
C145,146 257 3006 911 CF73=1C104JT(ECHUB5)
C147,148 254 4300 963 CE04W0J101MT(SRE)
C149 257 3006 911 CF73=1C104JT(ECHUB5)
C150 254 4305 900 CE04W1H0R1MT(SRE)
C151 254 4305 984 CE04W1H2R2MT(SRE)
C152 257 3014 987 CF73=1C223JT(ECHUB5)
C153-157 254 4305 900 CE04W1H0R1MT(SRE)
C158 257 0516 954 CK73B1E104KT
C159 254 4302 974 CE04W1A101MT(SRE)
C160 257 0503 941 CC73CH1H120JT
C161 257 0504 908 CC73CH1H220JT
C162 254 4300 934 CE04W0J220MT(SRE)
C163 254 4300 963 CE04W0J101MT(SRE)
C164,165 254 4300 918 CE04W0J100MT(SRE)
C166-168 254 4300 963 CE04W0J101MT(SRE)
C169-171 257 0501 901 CK73B1H103KT (1608)
C700-708 257 0506 951 CC73CH1H101JT
C709 257 0516 941 CK73B1E473KT
C710 257 0516 954 CK73B1E104KT
C711 256 1059 996 CF93A1H105JT(JL)
C712 254 4524 943 CE04W1H010MT SMG/RE3
C713 257 0516 941 CK73B1E473KT
OTHER PARTS GROUP
Q'ty
CW158 205 0885 040 15P CON.SOCKET TUC-P 1
CW951 205 0885 040 15P CON.SOCKET TUC-P 1
CX911 205 0375 000 10P CON.BASE(KR-PH) 1
CX962 205 0343 061 6P CONN.BASE(KR-PH) 1
CY911 205 0375 000 10P CON.BASE(KR-PH) 1
CY962 205 0343 061 6P CONN.BASE(KR-PH) 1
FB101,102 247 2018 903 RM73B--0R0KT 2
FB103-107 235 0130 903 CHIP EMIFIL(11A121) 5
JK701 204 8607 007 3P PIN JACK (S-GND) 1
JK702-704 204 6670 007 D CONNECTOR 3
JK705 204 8607 007 3P PIN JACK (S-GND) 1
L101,102 235 0150 938 LQH32MN270J23L 2
L103 235 0150 954 LQH32MN101J23L 1
L107 235 0150 938 LQH32MN270J23L 1
RL701-710 214 0223 004 RELAY(EC2-24N35) 10
ST101,102 205 0452 017 STYLE PIN 2
ST201,202 205 0452 017 STYLE PIN 2
ST205 205 0452 017 STYLE PIN 1
X101 399 0809 004 X’TAL(4.43MHZ) 1
X102 399 0802 001 X’TAL(3.58MHZ) 1
X103 399 0810 006 CSB503F30 1
