Denon AVR-3806 Service Manual

65
AVR-3806 / AVC-3920
1U-3701 POWER AMP P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC603 00D 263 1035 002 PQ30RV11
! IC604 00D 268 0073 905 ICP-N15T
TR105,106 00D 273 0458 904 2SC/KTC3200BL-AT
TR205 00D 273 0458 904 2SC/KTC3200BL-AT
TR305,306 00D 273 0458 904 2SC/KTC3200BL-AT
TR405,406 00D 273 0458 904 2SC/KTC3200BL-AT
TR501-506 00D 273 0464 901 KTC3875SGR-RTK +C
TR507 00D 271 0301 903 2SA/KTA1268BL-AT
TR601 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR602 00D 273 0464 901 KTC3875SGR-RTK +C
TR609 00D 273 0464 901 KTC3875SGR-RTK +C
D101-106 00D 276 0432 903 1SS270A TE (TAPE)
D201 00D 276 0432 903 1SS270A TE (TAPE)
D203 00D 276 0432 903 1SS270A TE (TAPE)
D205 00D 276 0432 903 1SS270A TE (TAPE)
D301-306 00D 276 0432 903 1SS270A TE (TAPE)
D401-406 00D 276 0432 903 1SS270A TE (TAPE)
D501-506 00D 276 0432 903 1SS270A TE (TAPE)
D507,508 00D 276 0338 007 S4VB20F
D601 00D 276 0794 900 KDS160 +2125
D602 00D 276 0704 903 1SR35-400A(T93X)
D604,605 00D 276 0704 903 1SR35-400A(T93X)
D607 00D 276 0704 903 1SR35-400A(T93X)
D611,612 00D 276 0704 903 1SR35-400A(T93X)
ZD101-104 00D 276 0461 903 HZS6A-1TD
ZD201 00D 276 0461 903 HZS6A-1TD
ZD203 00D 276 0461 903 HZS6A-1TD
ZD301-304 00D 276 0461 903 HZS6A-1TD
ZD401-404 00D 276 0461 903 HZS6A-1TD
ZD601 00D 276 0645 907 MTZJ18A T77
ZD603 00D 276 0798 919 UDZS6.8B-TE17
RESISTORS GROUP
R103-106 00D 241 2378 920 RD14B2E221JNBST
R107-114 00D 244 2671 956 RS14B3DR47JNBST(S)
R203 00D 241 2378 920 RD14B2E221JNBST
R205 00D 241 2378 920 RD14B2E221JNBST
R207 00D 244 2671 956 RS14B3DR47JNBST(S)
R209 00D 244 2671 956 RS14B3DR47JNBST(S)
R211 00D 244 2671 956 RS14B3DR47JNBST(S)
R213 00D 244 2671 956 RS14B3DR47JNBST(S)
R303-306 00D 241 2378 920 RD14B2E221JNBST
R307-314 00D 244 2671 956 RS14B3DR47JNBST(S)
R403-406 00D 241 2378 920 RD14B2E221JNBST
R407-414 00D 244 2671 956 RS14B3DR47JNBST(S)
R501,502 00D 244 2682 945 RS14B3D2R2JNBST(S)
R503,504 00D 244 2671 901 RS14B3D100JNBST(S)
R507 00D 244 2682 945 RS14B3D2R2JNBST(S)
R508 00D 244 2671 901 RS14B3D100JNBST(S)
R511,512 00D 244 2682 945 RS14B3D2R2JNBST(S)
R513,514 00D 244 2671 901 RS14B3D100JNBST(S)
R517,518 00D 244 2052 960 RS14B3A221JNBST(S)
R521,522 00D 244 2052 960 RS14B3A221JNBST(S)
R527,528 00D 244 2682 945 RS14B3D2R2JNBST(S)
R529,530 00D 244 2671 901 RS14B3D100JNBST(S)
R531,532 00D 243 2039 032 RW99=3H0R1K
R535 00D 244 2051 961 RS14B3A101JNBST(S)
R536 00D 241 2387 940 RD14B2E4R7JNBST
