Denon AVR-3806 Service Manual

66
AVR-3806 / AVC-3920
R606 00D 247 0049 990 RM73B--513DT
R607 00D 247 0051 904 RM73B--154DT
R608 00D 247 0048 920 RM73B--103DT
R610 00D 244 2050 933 RS14B3A181JNBST(S)
R624 00D 242 2009 001 RC05GF2H225K(UL)
VR101,102 00D 211 6131 939 V06PB331T
VR201 00D 211 6131 939 V06PB331T
VR301,302 00D 211 6131 939 V06PB331T
VR401,402 00D 211 6131 939 V06PB331T
CAPACITORS GROUP
C101,102 00D 254 4586 949 CE04W2A100MT(RE3)
C103-106 00D 254 4586 936 CE04W2A4R7MT(RE3)
C201 00D 254 4586 949 CE04W2A100MT(RE3)
C203 00D 254 4586 936 CE04W2A4R7MT(RE3)
C205 00D 254 4586 936 CE04W2A4R7MT(RE3)
C301,302 00D 254 4586 949 CE04W2A100MT(RE3)
C303-306 00D 254 4586 936 CE04W2A4R7MT(RE3)
C401,402 00D 254 4586 949 CE04W2A100MT(RE3)
C403-406 00D 254 4586 936 CE04W2A4R7MT(RE3)
C501,502 00D 255 1279 919 CQ93M1H473JT(B)
C503,504 00D 255 1264 982 CQ93M1H472JT(B)
C505,506 nsp 00D 257 0509 929 CK73B1H102KT +1608
C507 00D 255 1279 919 CQ93M1H473JT(B)
C508 00D 255 1264 982 CQ93M1H472JT(B)
C509 nsp 00D 257 0509 929 CK73B1H102KT +1608
C510,511 00D 255 1279 919 CQ93M1H473JT(B)
C512,513 00D 255 1264 982 CQ93M1H472JT(B)
C514,515 nsp 00D 257 0509 929 CK73B1H102KT +1608
C516,517 00D 255 1279 919 CQ93M1H473JT(B)
C518-521 00D 255 1264 982 CQ93M1H472JT(B)
C522-525 nsp 00D 257 0509 929 CK73B1H102KT +1608
C526 00D 254 4573 949 CE04W1H010MT(RE3)
C528,529 00D 254 6257 001 CE68W==153M(DL)
C530-532 00D 256 1064 907 CF93A2E334KT(B)L=16
C533 00D 254 4587 715 CE04W2A101MC(RE3)
C603 00D 254 4573 981 CE04W1H100MT(RE3)
C605 00D 254 4760 736 CE04W1E682MC(SMQ)
C606 00D 254 4573 949 CE04W1H010MT(RE3)
C607 00D 255 1279 951 CQ93M1H104JT(B)
C617 00D 254 4573 949 CE04W1H010MT(RE3)
C625 00D 253 8022 707 CK45F2EAC103MC
OTHERS PARTS GROUP
! AC601 00D 203 3976 002 AC OUTLET(2P)
CW042 nsp 00D 203 6633 009 4P KR-DA CON.CORD
CW972 nsp 00D 205 0942 022 7P CON.SOCKET
CW978 nsp 00D 205 0942 022 7P CON.SOCKET
CX022 nsp 00D 205 0768 002 2P VH CON.BASE (BLK)
CX023 nsp 00D 205 0581 001 2P VH CONNECTOR BASE
CX055 nsp 00D 205 0653 052 5P VH CONNECTOR BASE
CX091 nsp 00D 205 0884 038 9P CON.BASE TUC-P
CX111 nsp 00D 205 1091 024 11P CON BASE TWG-P
CX131 nsp 00D 205 1091 037 13P CON BASE TWG-P
CX961-966 nsp 00D 205 0943 018 6P CON.BASE(TUC-P)
CX971,972 nsp 00D 205 0943 021 7P CON.BASE(TUC-P)
CX978 nsp 00D 205 0943 021 7P CON.BASE(TUC-P)
CY021 nsp 00D 205 0581 069 2P VH-VH CON BASE
! F001 00D 206 1086 003 FUSE 8A (UL/CSA/J)
! F008 00D 206 1046 014 FUSE 8A
Ref. No. nsp Part No. Part Name Remarks Q'ty New
