Denon AVR-3806 Service Manual

77
AVR-3806 / AVC-3920
C269,270 nsp 00D 257 0507 976 CC73CH1H331JT +1608
C273,274 00D 254 4573 981 CE04W1H100MT(RE3)
C301,302 00D 254 4574 906 CE04W1H330MT(RE3)
C303-310 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C311-314 00D 254 4574 906 CE04W1H330MT(RE3)
C315-320 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C321 00D 254 4574 906 CE04W1H330MT(RE3)
C322-325 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C326-328 00D 254 4574 906 CE04W1H330MT(RE3)
C329-332 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C333,334 00D 254 4574 906 CE04W1H330MT(RE3)
C335,336 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C337,338 00D 254 4577 945 CE04W1C101MT(RE3)
C339 nsp 00D 257 0516 941 CK73B1E473KT +1608
C340 00D 254 4573 949 CE04W1H010MT(RE3)
C341 nsp 00D 257 0516 941 CK73B1E473KT +1608
C342 nsp 00D 257 0516 954 CK73B1E104KT +1608
C343 nsp 00D 257 0516 941 CK73B1E473KT +1608
C348,349 00D 254 4577 945 CE04W1C101MT(RE3)
C350,351 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C401,402 00D 254 4573 981 CE04W1H100MT(RE3)
C403,404 00D 254 4574 906 CE04W1H330MT(RE3)
C413,414 00D 254 4573 981 CE04W1H100MT(RE3)
C417,418 00D 254 4573 994 CE04W1H220MT(RE3)
C419,420 00D 254 4573 981 CE04W1H100MT(RE3)
C423,424 00D 254 4573 994 CE04W1H220MT(RE3)
C431-434 00D 254 4573 981 CE04W1H100MT(RE3)
C436,437 nsp 00D 257 0507 976 CC73CH1H331JT +1608
C439-442 00D 254 4573 981 CE04W1H100MT(RE3)
C445,446 00D 254 4573 994 CE04W1H220MT(RE3)
C447 00D 254 4573 949 CE04W1H010MT(RE3)
C501,502 00D 254 4573 994 CE04W1H220MT(RE3)
C503 00D 254 4573 907 CE04W1H0R1MT(RE3)
C504,505 00D 254 4573 994 CE04W1H220MT(RE3)
C506 00D 254 4573 907 CE04W1H0R1MT(RE3)
C507,508 00D 254 4573 994 CE04W1H220MT(RE3)
C509 00D 254 4573 907 CE04W1H0R1MT(RE3)
C510,511 00D 254 4573 994 CE04W1H220MT(RE3)
C512 00D 254 4573 907 CE04W1H0R1MT(RE3)
C513,514 00D 254 4573 994 CE04W1H220MT(RE3)
C515 00D 254 4573 907 CE04W1H0R1MT(RE3)
C519,520 00D 254 4573 994 CE04W1H220MT(RE3)
C521 00D 254 4573 907 CE04W1H0R1MT(RE3)
C525,526 00D 254 4573 981 CE04W1H100MT(RE3)
C702,703 nsp 00D 257 0516 954 CK73B1E104KT +1608
C704,705 00D 254 4574 906 CE04W1H330MT(RE3)
C706 00D 254 4577 945 CE04W1C101MT(RE3)
C708 nsp 00D 257 0506 977 CC73CH1H121JT +1608
C709 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C710,711 nsp 00D 257 0503 925 CC73CH1H100DT +1608
C712 00D 255 1265 978 CQ93M1H223JT(B)
C713 00D 254 4573 978 CE04W1H4R7MT(RE3)
C714 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C715 00D 254 4573 949 CE04W1H010MT(RE3)
C716 00D 254 4573 981 CE04W1H100MT(RE3)
C717 00D 254 4577 945 CE04W1C101MT(RE3)
C718 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C719 nsp 00D 257 0506 993 CC73CH1H151JT +1608
C720 00D 254 4573 949 CE04W1H010MT(RE3)
C721 00D 255 1279 935 CQ93M1H683JT(B)
C722 nsp 00D 257 0508 917 CC73CH1H471JT +1608
C723 nsp 00D 257 0510 918 CK73B1H332KT +1608
C724,725 nsp 00D 257 0504 940 CC73CH1H330JT +1608
C726 00D 254 4577 945 CE04W1C101MT(RE3)
C727 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C728 00D 254 4573 981 CE04W1H100MT(RE3)
C729 nsp 00D 257 0509 929 CK73B1H102KT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
