Denon AVR-3806 Service Manual

78
AVR-3806 / AVC-3920
C730 nsp 00D 257 0509 945 CK73B1H122KT +1608
C731,732 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C733-735 00D 254 4577 945 CE04W1C101MT(RE3)
C736,737 00D 254 4574 906 CE04W1H330MT(RE3)
C738 00D 254 4573 981 CE04W1H100MT(RE3)
C739-741 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C743,744 nsp 00D 257 0516 954 CK73B1E104KT +1608
C745-750 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C824 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C825 00D 254 4573 978 CE04W1H4R7MT(RE3)
C826 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C901 00D 257 2015 903 CS77B1A100MT
C902,903 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C904 00D 254 4533 947 CE04W0J331MT SMG/RE3
C905 00D 257 2015 903 CS77B1A100MT
C906 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C907 00D 254 4533 947 CE04W0J331MT SMG/RE3
C935 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C936 nsp 00D 257 0509 929 CK73B1H102KT +1608
C937 00D 254 4573 981 CE04W1H100MT(RE3)
C938 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C939 nsp 00D 257 0509 929 CK73B1H102KT +1608
C940,941 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C942-944 00D 257 0521 949 CK73B1A474KT
C945 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C946,947 nsp 00D 257 0507 934 CC73CH1H221JT +1608
C948-951 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C953 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C954,955 00D 254 4196 944 CE04W1H010MT (SRA)
C957 00D 254 4305 968 CE04W1H010MT(SRE)
C958 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C959 nsp 00D 257 0506 993 CC73CH1H151JT +1608
C960,961 00D 254 4305 968 CE04W1H010MT(SRE)
C962 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C963 nsp 00D 257 0506 993 CC73CH1H151JT +1608
C967 nsp 00D 257 0516 954 CK73B1E104KT +1608
C968,969 00D 254 4305 968 CE04W1H010MT(SRE)
C970,971 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC413,414 nsp 00D 257 0507 976 CC73CH1H331JT +1608
CC415-426 nsp 00D 257 0507 976 CC73CH1H331JT +1608
CC427-432 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC433-448 00D 254 4573 981 CE04W1H100MT(RE3)
CC465-480 00D 254 4574 906 CE04W1H330MT(RE3)
CC481,482 00D 254 4573 981 CE04W1H100MT(RE3)
OTHERS PARTS GROUP
CW115-118 nsp 00D 205 0885 066 11P CON.SOCKET TUC-P
CW133 nsp 00D 205 0942 006 13P CON.SOCKET(TUC-P
CW136 nsp 00D 205 1326 032 13P SOCKET(9120)
CW144 nsp 00D 205 1326 045 14P SOCKET(9120)
CW153-156 nsp 00D 205 0885 040 15P CON.SOCKET TUC-P
CW158 nsp 00D 205 0885 040 15P CON.SOCKET TUC-P
CW162 nsp 00D 205 0942 051 16P CON.SOCKET TUC-P
CW951 nsp 00D 205 0885 008 5P CON.SOCKET TUC-P
CW974 nsp 00D 205 0942 022 7P CON.SOCKET(TUC-P
CX034 nsp 00D 205 0406 034 3P CON BASE(KR-PH)
CX053 nsp 00D 205 0321 054 5P CONNE.BASE (RED)
CX058 nsp 00D 205 0885 008 5P CON.SOCKET TUC-P
CX121 nsp 00D 205 0885 079 12P CON.SOCKET TUC-P
CX145 nsp 00D 205 1228 020 14P FJ CONN.BASE
CX171 nsp 00D 205 0770 029 17P FFC CON BASE
CX181 nsp 00D 205 1378 909 18P FFC BASE(9610SD)
CX914 nsp 00D 205 1228 017 11P FJ CONN.BASE
CY058 nsp 00D 205 0884 009 5P CON.BASE TUC-P
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
