80
AVR-3806 / AVC-3920
1U-3705 DIGITAL P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101-103 00D 262 3449 004 LC89057W-VF4A
IC151 00D 262 3068 003 EPM3128ATC144-10 +REF
IC152 00D 262 3062 902 FCX0-03(24.576MHZ) +REF
IC201 00D 262 3550 003 ADSP-21366SKBCZ
IC202 00D 262 3557 909 FCXO-03L(20.815MHZ)
IC205 00D 262 3339 907 SN74LVC139APWR +REF
IC206,207 00D 262 3559 907 TC74VHC573FT
IC208 00D GEN 8015 DSP SUB ASS'Y LH28F160BJE-BTL90
IC209,210 00D 262 3341 005 CY7C1049CV33-10ZC +REF
IC251 00D GEN 8014 SUB CPU SUB ASS'Y M30620FCPGP(3805-S)
IC252 00D 262 2517 908 SN74LV08APW-EL2 +REF
IC254 00D 262 3410 907 TC74VHCT08AFT
IC301 00D 262 3069 905 PCM1804 +REF
IC302-305 00D 262 3332 904 PCM1791ADBR +REF
IC306 00D 263 1079 903 BA033FP +C
IC307-309 00D 263 0934 900 BA4510F-E2 +C
IC310-314 00D 262 3555 901 SA5532ADR
IC351 00D 262 3552 904 AK4385ET
IC353 00D 263 0615 902 BA15218F-DXE2 +C
IC401 00D 262 3431 012 SII9031CTU-7
IC402 00D 262 3265 903 LM1117MPX-1.8 +C
IC403,404 00D 262 3416 901 BR24L02F-WE2
IC451 00D 262 3364 011 SII9030CTU-7
IC452 00D 262 3265 903 LM1117MPX-1.8 +C
IC601 00D 262 3495 003 ADV7403BSTZ-110
IC604 00D 262 3519 905 PQ018EZ01ZPH
IC605 00D 262 2977 917 BA25BC0FP-E2
IC606 00D 263 1079 903 BA033FP +C
IC607 00D 262 3519 905 PQ018EZ01ZPH
IC608 00D 262 2977 917 BA25BC0FP-E2
IC610 00D 262 3478 004 ADV7320
IC611 00D 262 3365 900 BH7868FS
IC612,613 00D 263 1082 903 TK15420MTL +C
IC614 00D 263 1198 907 LT1399CS +REF
IC617 00D 262 3425 905 LTC4300-2CMS8
IC701,702 00D 262 3553 000 LC4064V-75TN100C
IC841 00D 262 3517 907 F2602-01-TR
IC842 00D 262 3516 908 FCXO-03L(45.1584MHZ)
IC844 00D 262 2517 908 SN74LV08APW-EL2 +REF
TR201 00D 269 0184 907 KRA102S-RTK +C
TR253,254 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR303 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR304 00D 269 0184 907 KRA102S-RTK +C
TR305-312 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR313-316 00D 269 0184 907 KRA102S-RTK +C
TR317,318 00D 273 0460 905 KTC2875B-RTK +C
TR319 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR320 00D 269 0184 907 KRA102S-RTK +C
TR351 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR353 00D 269 0184 907 KRA102S-RTK +C
TR357 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR359 00D 269 0184 907 KRA102S-RTK +C
TR401-404 00D 275 0110 905 HN1K02FU-TE85L
TR405 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR406 00D 269 0184 907 KRA102S-RTK +C
TR407 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR408 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR409 00D 269 0184 907 KRA102S-RTK +C
TR410 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR411 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR413 00D 275 0110 905 HN1K02FU-TE85L
