Denon AVR-3806 Service Manual

81
AVR-3806 / AVC-3920
TR451 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR452 00D 275 0110 905 HN1K02FU-TE85L
TR454 00D 273 0464 901 KTC3875SGR-RTK +C
TR455 00D 269 0184 907 KRA102S-RTK +C
TR601,602 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR603-607 00D 271 0293 901 2SA1022-B +C
D201 00D 276 0750 902 RB521S-30TE61 +REF
D304-307 00D 276 0740 909 KDS184-RTK(K-COM) +C
D351 00D 276 0740 909 KDS184-RTK(K-COM) +C
D401-404 00D 276 0750 902 RB521S-30TE61 +REF
D405-407 00D 276 0794 900 KDS160 +2125
D451 00D 276 0794 900 KDS160 +2125
D457-464 00D 276 0833 900 ESD PROTECTOR(6802)
ZD841 00D 276 0829 901 NSAD500F-T1B
X251 00D 399 1038 900 FCX-03(12MHZ)
X401 00D 399 1039 909 FCX-03(28.322MHZ)
X601 00D 399 1000 909 FCX-03(28.63636MHZ)
RESISTORS GROUP
RR848 00D 247 1018 904 RM73B20R0KT +3216
RR869 00D 247 1018 904 RM73B20R0KT +3216
L604 00D 247 1018 904 RM73B20R0KT +3216
L607 00D 247 1018 904 RM73B20R0KT +3216
VR601-605 00D 211 6148 906 V03PB471MT(RH03ADCS) +REF
CAPACITORS GROUP
C101 nsp 00D 257 0516 954 CK73B1E104KT +1608
C102 00D 257 2015 903 CS77B1A100MT
C104 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C105 00D 257 3024 964 CF73=1C104JT(ECHUX)
C107 00D 257 3023 981 CF73=1C223JT(ECHUX)
C108 nsp 00D 257 0516 954 CK73B1E104KT +1608
C109 00D 257 2015 903 CS77B1A100MT
C111 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C112 00D 257 3024 964 CF73=1C104JT(ECHUX)
C114 00D 257 3023 981 CF73=1C223JT(ECHUX)
C115 nsp 00D 257 0516 954 CK73B1E104KT +1608
C116 00D 257 2015 903 CS77B1A100MT
C118 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C119 00D 257 3024 964 CF73=1C104JT(ECHUX)
C121 00D 257 3023 981 CF73=1C223JT(ECHUX)
C122-127 nsp 00D 257 0509 929 CK73B1H102KT +1608
C201 00D 254 4601 918 CE67W0J471MT(P.CAP) +REF
C203 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C205-209 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C210 00D 257 2015 903 CS77B1A100MT
C211-219 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C220 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C221 00D 257 2015 903 CS77B1A100MT
C222,223 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C224 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C225 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C227,228 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C230,231 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C233-236 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C242 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C243 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C244 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C245,246 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C247 nsp 00D 257 0506 951 CC73CH1H101JT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
