Denon AVR-3806 Service Manual

82
AVR-3806 / AVC-3920
C248 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C249,250 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C251 00D 257 2015 903 CS77B1A100MT
C252 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C253 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C255,256 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C266 nsp 00D 257 0516 954 CK73B1E104KT +1608
C301,302 00D 257 3018 925 CF73=1H102JT(ECHUX)
C303-306 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C307,308 nsp 00D 254 4465 921 CE67C1C100MT +REF
C310 nsp 00D 257 0509 929 CK73B1H102KT +1608
C312 nsp 00D 257 0516 954 CK73B1E104KT +1608
C313 00D 254 4465 921 CE67C1C100MT +REF
C314 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
C315-318 00D 254 4465 921 CE67C1C100MT +REF
C319 00D 257 2015 903 CS77B1A100MT
C320 00D 254 4465 921 CE67C1C100MT +REF
C321 nsp 00D 257 0516 954 CK73B1E104KT +1608
C322 nsp 00D 257 0509 929 CK73B1H102KT +1608
C325,326 nsp 00D 257 0516 954 CK73B1E104KT +1608
C327 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
C328 00D 254 4604 986 CE67W1H100MT(P.CAP) +REF
C329 00D 257 3018 941 CF73=1H152JT(ECHUX)
C330 00D 257 3018 954 CF73=1H182JT(ECHUX)
C331 00D 257 3017 971 CF73=1H391JT(ECHUX)
C332 00D 257 3017 997 CF73=1H561JT(ECHUX)
C333 00D 257 3017 971 CF73=1H391JT(ECHUX)
C334 00D 257 3017 997 CF73=1H561JT(ECHUX)
C335,336 00D 254 4603 916 CE67W1E100MT(P.CAP) +REF
C337,338 nsp 00D 257 0516 954 CK73B1E104KT +1608
C339 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
C340 00D 254 4604 986 CE67W1H100MT(P.CAP) +REF
C341 00D 257 3018 954 CF73=1H182JT(ECHUX)
C342 00D 257 3018 941 CF73=1H152JT(ECHUX)
C343 00D 257 3017 997 CF73=1H561JT(ECHUX)
C344 00D 257 3017 971 CF73=1H391JT(ECHUX)
C345 00D 257 3017 997 CF73=1H561JT(ECHUX)
C346 00D 257 3017 971 CF73=1H391JT(ECHUX)
C347,348 00D 257 2015 903 CS77B1A100MT
C349,350 nsp 00D 257 0516 954 CK73B1E104KT +1608
C352 00D 254 4604 986 CE67W1H100MT(P.CAP) +REF
C353,354 00D 257 3018 954 CF73=1H182JT(ECHUX)
C355-358 00D 257 3017 997 CF73=1H561JT(ECHUX)
C359,360 nsp 00D 257 0516 954 CK73B1E104KT +1608
C362 00D 254 4604 986 CE67W1H100MT(P.CAP) +REF
C363 00D 257 3018 941 CF73=1H152JT(ECHUX)
C364 00D 257 3018 954 CF73=1H182JT(ECHUX)
C365 00D 257 3017 926 CF73=1H151JT(ECHUX)
C366 00D 257 3017 997 CF73=1H561JT(ECHUX)
C367 00D 257 3017 926 CF73=1H151JT(ECHUX)
C368 00D 257 3017 997 CF73=1H561JT(ECHUX)
C371,372 00D 257 2015 903 CS77B1A100MT
C401,402 nsp 00D 257 0516 954 CK73B1E104KT +1608
C403 nsp 00D 257 0509 929 CK73B1H102KT +1608
C404-408 nsp 00D 257 0516 954 CK73B1E104KT +1608
C409-413 nsp 00D 257 0509 929 CK73B1H102KT +1608
C414 00D 257 2015 903 CS77B1A100MT
C416 00D 257 2015 903 CS77B1A100MT
C417,418 nsp 00D 257 0516 954 CK73B1E104KT +1608
C420 nsp 00D 257 0509 929 CK73B1H102KT +1608
C421-424 nsp 00D 257 0516 954 CK73B1E104KT +1608
C425,426 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C427-434 nsp 00D 257 0516 954 CK73B1E104KT +1608
C435-438 nsp 00D 257 0509 929 CK73B1H102KT +1608
C439 nsp 00D 257 0503 967 CC73CH1H150JT +1608
C440 nsp 00D 257 0509 929 CK73B1H102KT +1608
C441 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
