Denon AVR-3806 Service Manual

83
AVR-3806 / AVC-3920
C442 nsp 00D 257 0503 967 CC73CH1H150JT +1608
C443-451 nsp 00D 257 0509 929 CK73B1H102KT +1608
C455 00D 257 2015 903 CS77B1A100MT
C457 nsp 00D 257 0509 929 CK73B1H102KT +1608
C462 00D 257 2015 903 CS77B1A100MT
C463,464 nsp 00D 257 0516 954 CK73B1E104KT +1608
C465 00D 257 2015 903 CS77B1A100MT
C466 nsp 00D 257 0516 954 CK73B1E104KT +1608
C467 nsp 00D 257 0509 929 CK73B1H102KT +1608
C468 nsp 00D 257 0516 954 CK73B1E104KT +1608
C469 00D 257 2015 903 CS77B1A100MT
C601 nsp 00D 257 0516 954 CK73B1E104KT +1608
C603 nsp 00D 257 0516 954 CK73B1E104KT +1608
C605 nsp 00D 257 0516 954 CK73B1E104KT +1608
C606 00D 257 2015 903 CS77B1A100MT
C609-613 nsp 00D 257 0516 954 CK73B1E104KT +1608
C614,615 00D 254 4572 908 CE67C1C100MT(MV-B) +REF
C617,618 00D 254 4572 908 CE67C1C100MT(MV-B) +REF
C619,620 nsp 00D 257 0516 954 CK73B1E104KT +1608
C621,622 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C624-628 nsp 00D 257 0516 954 CK73B1E104KT +1608
C629 nsp 00D 257 0509 929 CK73B1H102KT +1608
C630 nsp 00D 257 0516 954 CK73B1E104KT +1608
C632 00D 257 3023 949 CF73=1C103JT(ECHUX)
C633 00D 257 3024 951 CF73=1C823JT(ECHUX)
C634 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C636 nsp 00D 257 0516 954 CK73B1E104KT +1608
C638 nsp 00D 257 0516 954 CK73B1E104KT +1608
C639,640 nsp 00D 257 0502 984 CC73CH1H6R0DT +1608
C642 nsp 00D 257 0516 954 CK73B1E104KT +1608
C643 00D 254 4464 906 CE67C0J101MT +REF
C644 nsp 00D 257 0509 929 CK73B1H102KT +1608
C645 00D 257 2015 903 CS77B1A100MT
C646-648 nsp 00D 257 0509 929 CK73B1H102KT +1608
C649 00D 257 2015 903 CS77B1A100MT
C650,651 nsp 00D 257 0509 929 CK73B1H102KT +1608
C652 00D 257 2015 903 CS77B1A100MT
C653 00D 254 4464 906 CE67C0J101MT +REF
C654 nsp 00D 257 0509 929 CK73B1H102KT +1608
C655 00D 257 2015 903 CS77B1A100MT
C656-658 nsp 00D 257 0509 929 CK73B1H102KT +1608
C659 00D 257 2015 903 CS77B1A100MT
C662,663 nsp 00D 257 0516 954 CK73B1E104KT +1608
C665 00D 257 2015 903 CS77B1A100MT
C666,667 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C669 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C670,671 nsp 00D 257 0516 954 CK73B1E104KT +1608
C672 00D 257 3018 912 CF73=1H821JT(ECHUX)
C673 00D 257 2015 903 CS77B1A100MT
C674 nsp 00D 257 0516 954 CK73B1E104KT +1608
C675 00D 257 3022 995 CF73=1C392JT(ECHUX)
C683-687 nsp 00D 257 0516 954 CK73B1E104KT +1608
C717 nsp 00D 257 0509 929 CK73B1H102KT +1608
C718 nsp 00D 257 0516 954 CK73B1E104KT +1608
C719 00D 257 2015 903 CS77B1A100MT
C720-723 nsp 00D 257 0509 929 CK73B1H102KT +1608
C724 nsp 00D 257 0516 954 CK73B1E104KT +1608
C726-729 nsp 00D 257 0509 929 CK73B1H102KT +1608
C730 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C731 nsp 00D 257 0516 954 CK73B1E104KT +1608
C732 nsp 00D 257 0509 929 CK73B1H102KT +1608
C733 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C734 nsp 00D 257 0516 954 CK73B1E104KT +1608
C735 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC152-154 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC155-159 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC160,161 nsp 00D 257 0506 951 CC73CH1H101JT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
