Denon AVR-3806 Service Manual

84
AVR-3806 / AVC-3920
CC162-168 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC169,170 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC171 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC172 00D 257 2015 903 CS77B1A100MT
CC173 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC174 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC251,252 nsp 00D 257 0503 925 CC73CH1H100DT +1608
CC253 00D 257 2015 903 CS77B1A100MT
CC254,255 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC256,257 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC258,259 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC260 nsp 00D 257 0506 951 CC73CH1H101JT +1608
CC261 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC262 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC263 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC355 00D 254 4604 944 CE67W1H010MT(P.CAP)
CC365,366 nsp 00D 257 0510 918 CK73B1H332KT +1608
CC369,370 nsp 00D 257 0508 917 CC73CH1H471JT +1608
CC373,374 nsp 00D 257 0508 917 CC73CH1H471JT +1608
CC451 00D 257 2015 903 CS77B1A100MT
CC452 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC453,454 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC455 00D 257 2015 903 CS77B1A100MT
CC456 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC457-459 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC460,461 00D 257 2015 903 CS77B1A100MT
CC462 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC463,464 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC465 00D 257 2015 903 CS77B1A100MT
CC466,467 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC468-470 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC472-476 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC601,602 nsp 00D 257 0506 977 CC73CH1H121JT +1608
CC603-606 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC607-609 00D 254 4464 906 CE67C0J101MT +REF
CC610 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC612 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC614 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC616 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC624 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
CC625 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC626 00D 254 4601 934 CE67W0J101MT(P.CAP) +REF
CC627 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC628,629 00D 254 4464 906 CE67C0J101MT +REF
CC630 00D 254 4464 906 CE67C0J101MT +REF
CC631 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
CC632 00D 254 4464 906 CE67C0J101MT +REF
CC633 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
CC634 00D 254 4464 906 CE67C0J101MT +REF
CC635 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
CC636 00D 254 4655 977 CE67C0J102MT (RV) +REF
CC638 00D 254 4464 906 CE67C0J101MT +REF
CC640 00D 254 4464 906 CE67C0J101MT +REF
CC641 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC642 00D 254 4464 906 CE67C0J101MT +REF
CC643-645 00D 254 4572 908 CE67C1C100MT(MV-B) +REF
CC646 00D 254 4464 951 CE67C0J220MT(MV-B) +REF
CC647 00D 254 4572 908 CE67C1C100MT(MV-B) +REF
CC649-651 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
CC652 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC801 nsp 00D 257 0509 929 CK73B1H102KT +1608
CC802 00D 257 2015 903 CS77B1A100MT
CC803 nsp 00D 257 0503 996 CC73CH1H200JT +1608
CC804 00D 254 4465 905 CE67C1C220MT +REF
CC808-810 nsp 00D 257 0503 996 CC73CH1H200JT +1608
CC811,812 nsp 00D 257 0516 954 CK73B1E104KT +1608
CC814 nsp 00D 257 0516 954 CK73B1E104KT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
