'- 48 '3
4-
43
4#
3
4#
-
ZONE3 audio output
Main zone (7.1-channel system)
Monitor
ZONE2
ZONE3
DVD player
Input
Remote
control unit
ZONE2
audio output
ZONE2
video output
AVR-3808CI
Monitor
Power amplifier
Power amplifier
: Multi-zone video cable
: Multi-zone audio cable
When only using one speaker for ZONE2 or ZONE3, set to “Mono. In this case, the ZONE2 (ZONE3)
monaural output is output from the ZONE2 (ZONE3) pre-out L and R connectors, so connect as desired.
Separate power amplifiers are needed for ZONE2 and ZONE3.
Multi-Zone
Connectors for audio output Audio signals Connectors for video output
ZONE2 ZONE2 PRE OUT Stereo ZONE2 VIDEO OUT
ZONE3 ZONE3 PRE OUT Stereo
Multi-Zone Settings and Operations with Zone Pre-out
Output
Prepare power amplifiers for ZONE2 and ZONE3.
0
Getting Started Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
Remote
control unit
Setting 4 :
F Making bi-amp connections for the FL and FR channels in the main zone
and conducting 5.1-channel playback
(switching with other modes not possible)
Speaker terminal
Amp Assign mode
FRONT
CENTER
SURR-A SURR-B
SURR. BACK /
AMP ASSIGN
R L R L R L R L
Bi-Amp FR FL C SR-A SL-A SR-B SL-B
FR FL
FL/FR Bi-Amp
connection
FL
SW C FR
B
A
SL
B
A
SR
Main zone
5.1ch
FL/FR
Bi-Amp
Bi-Amp
Both A and B can be installed for SR and SL.
Amp Assign mode:
n Amp Assign mode setting and speakers connected to the various speaker
terminals
