40
AVR-4802/AVC-A11SR
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
R811 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R814 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R815-817 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R818 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R819 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R820 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R822-825 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R827 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R828 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT
R829 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R831 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R832 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R833-835 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R837,838 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R839 241 2387 908 Carbon film 1 ohm 1/4W(NB) RD14B2E010JNBST
R840,841 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R843 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R844,845 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R846 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT
R847 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
AVC MODEL ONLY
R849,850 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R851 247 2001 981 Carbon chip 4.7 ohm 1/16W RM73B--4R7KT
R852 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R853 247 2001 981 Carbon chip 10 kohm 1/16W RM73B--103JT
R854 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R855 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R856 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R857 247 2007 985 Carbon chip 1.5 kohm 1/16W RM73B--152JT
R858 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT
R859 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R860 247 2005 903 Carbon chip 100 ohm 1/16W RM73B--101JT
R861 247 2013 908 Carbon chip 220 kohm 1/16W RM73B--224JT
R862 247 2011 942 Carbon chip 47 kohm 1/16W RM73B--473JT
R863 247 2004 920 Carbon chip 47 ohm 1/16W RM73B--470JT
R864 247 2007 943 Carbon chip 1 kohm 1/16W RM73B--102JT
R865 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R868 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R869 247 2001 981 Carbon chip 4.7 ohm 1/16W RM73B--4R7KT
R870 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R871 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R872 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R873 247 2012 925 Carbon chip 100 kohm 1/16W RM73B--104JT
R874 247 2013 908 Carbon chip 220 kohm 1/16W RM73B--224JT
R875 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R876 247 2009 909 Carbon chip 4.7 kohm 1/16W
RM73B--472JT (1608)
R877 247 2011 900 Carbon chip 33 kohm 1/16W RM73B--333JT
R878 247 2001 981 Carbon chip 4.7 ohm 1/16W RM73B--4R7KT
R880,881 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R883-887 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R889,890 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
AVR MODEL ONLY
R891 247 2009 983 Carbon chip 10 kohm 1/16W RM73B--103JT
R894 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
R897 247 2018 903 Carbon chip 0 ohm 1/16W RM73B--0R0KT
CAPACITORS GROUP
C101 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C107-109 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C110-112 254 4573 965 Electrolytic 3.3
µ
F/50V
CE04W1H3R3MT(RE3)
C113-119 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C120 254 4522 903 Electrolytic 4.7
µ
F/35V
CE04W1V4R7MT SMG/RE3
C122,123 257 0504 908 Ceramic chip 22pF/50V CC73CH1H220JT
C124 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C125 254 4573 981 Electrolytic 10
µ
F/50V
CE04W1H100MT(RE3)
C126 257 0504 908 Ceramic chip 22pF/50V CC73CH1H220JT
C127-130 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C131 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102KT
C132,133 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C134 257 0507 976 Ceramic chip 330pF/50V CC73CH1H331JT
C135 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C136 257 0516 909 Ceramic chip 0.022
µ
F/25V CK73B1E223KT
C137 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C138-141 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C142 257 0501 901 Ceramic chip 0.01
µ
F/50V
CK73B1H103KT (1608)
C144 255 4235 934 Mylar film 0.01
µ
F/100V CQ93P2A103JT(NH)
C145,146 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C147 254 4524 943 Electrolytic 1
µ
F/50V
CE04W1H010MT SMG/RE3
C148 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C149 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102KT
C150 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C151 254 4533 921 Electrolytic 100
µ
F/6.3V
CE04W0J101MT SMG/RE3
C152 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C153 257 0509 929 Ceramic chip 1000pF/50V CK73B1H102KT
C154,155 254 4538 900 Electrolytic 10
µ
F/16V
CE04W1C100MT SMG/RE3
C156 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C157 254 4522 903 Electrolytic 4.7
µ
F/35V
CE04W1V4R7MT SMG/RE3
C158,159 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C160 254 4522 903 Electrolytic 4.7
µ
F/35V
CE04W1V4R7MT SMG/RE3
C163,164 257 3011 948 Metalized chip 2200pF/50V CF73=1H222JT
(ECHUB5)
C165,166 254 4573 981 Electrolytic 10
µ
F/50V
E04W1H100MT(RE3)
C167,168 257 3010 907 Metalized chip 100pF/50V CF73=1H101JT
(ECHUB5)
C169,170 254 4577 945 Electrolytic 100
µ
F/16V
E04W1C101MT(RE3)
C171,172 254 4573 981 Electrolytic 10
µ
F/50V
CE04W1H100MT(RE3)
C173,174 257 0512 903 Ceramic chip 0.1
µ
F/25V CK73F1E104ZT
C175,176 254 4573 981 Electrolytic 10
µ
F/50V
CE04W1H100MT(RE3)
C178 257 0511 904 Ceramic chip 0.01
µ
F/50V CK73F1H103ZT
C181,182 254 4573 994 Electrolytic 22
µ
F/50V
CE04W1H220MT(RE3)
C183,184 254 4573 981 Electrolytic 10
µ
F/50V
CE04W1H100MT(RE3)
C185 257 3013 933 Ceramic chip 0.1
µ
F/50V CF73=1H104JT
(ECHUC9)
C187 257 0516 941 Ceramic chip 0.047
µ
F/25V CK73B1E473KT
C188,189 257 0511 917 Ceramic chip 0.022
µ
F/50V CK73F1H223ZT
